NEX 6620A User's Guide
1-1 Specifications
Specification
Model Available
NEX 6620A
NEX 6620
NEX 6620VL2
System Architecture
Standard ATX form factor with Dual Pentium III CPU support
AIO board with dual channel Ultra 160 SCSI, dual channel Ethernet and VGA
Next generation server board with industry specification
CPU Support
Intel Dual Pentium III CPU with 128/256K cache on die
Brand New Socket 370 FC-PGA CPU running at 100/133MHz FSB up to 1G+Hz
Support streaming SIMD instruction
Main Memory
Support DDR up to
DDR Socket x
ECC support (single bit error correction/Multiple bit errors reporting)
BIOS
Award System BIOS
Plug & Play support
Advanced Power Management support
Advanced Configuration & Power Interface support
Jumper less for CPU FSB
2M bits flash ROM
Chip Set
VIA Apollo PRO 266 Chipset ( VT 8633 and VT8233)
100/133MHz FSB support
PCI V2.2 complied
Intel 21150AB PCI to PCI Bridge
On Board VGA
C&T 69000/69030 PCI mode VGA controller
2MB/4MB SDRAM on die
Driver support：Windows 95/98/2000, Windows NT4.0
On Board LAN
Intel 82559 Single Ethernet controller ×2
10 Base T/100 Base TX support, full duplex
Complied with PCI V2.1, IEEE802.3, IEEE 802.3U
Introduction
-- ATX Dual Socket 370 Pentium III DDR Full Function Server Board
-- ATX Dual Socket 370 Pentium III DDR Server Board Basic Model
-- ATX Dual Socket 370 Pentium III DDR Server Board for 1U Server
4GB
(Max.)
4
Rev. B0
0301
1-2
