NEX 6620A User's Guide
When enabled, you can "wake-up" your system using a PCI rev.2.2 card, when a "PME" event occurring.
The Choice: Enabled, Disabled.
Modem Ring Resume
An input signal on the serial Ring Indicator(RI) line (in other words, an incoming call on the modem)
awakens the system from a soft off state..
The Choice: Enabled, Disabled.
RTC Alarm Resume
This is to enable or disable the feature of booting up the system on a scheduled time/date.
The Choice: Enabled, Disabled.
Date (of Month)
Specifies the date for RTC Alarm Resume.
The Choice: 0~31.
Resume Time (hh:mm: ss)
Specifies the time for RTC Alarm Resume.
Format is <hour><minute><second>.
► IRQs Activity Monitoring
Press <Enter> to enter the sub-menu, and you will see a sub-menu.
PM events whose occurrence can prevent the system from entering a power saving mode or can
awaken the system from such a mode. In effect, the system remains alert for anything which occurs to
a device which is configured as Enabled, even when the system is in a power down mode.
Primary INTR
When this is set to On, any event occurring will wake up the system which has been powered down.
The Choice: ON, OFF.
IRQ [3-15]
Enables or disables the monitoring of the specified IRQ line. If set to Enabled, the activity of the
specified IRQ line will prevent the system from entering power saving modes or awaken it from power
saving modes.
The Choice: Enabled, Disabled.
BIOS Setup
Rev. B0
0301
4-22
