Key Digital KD-MSV8X8 Specifications

Video/Audio Switchers
KD-MSV 8 X 8
KD-MSV8X8 is a Video Matrix Switcher capable of switching up to
8 Component Video Sources/Inputs to 8 independent Zones/Outputs
Key Benefits
4
Seamless matrix switching of up to 8 YPrPb (Component,
S-Video, Composite) Video to 8 independent Zones/Outputs
4
Capable of switching RGBHV signals by sharing 2 input
and 2 output zones
4
Incorporates 3 Key Digital
Key Solutions
Provides seamless switching from 8 YPrPb sources to 8 independent Zones/Outputs
›
Allows for multiple expansions of YPrPb sources to multiple displays in multiple zones
›
Video can be switched to black video (mute)
›
Control systems supported via RS-232/IR: AMX (supports AMX DDDP – Dynamic Device
›
Discovery Protocol), Crestron, Control4, RTI, Universal, Xantech and more
Key Digital
0
Exclusive Technologies
®
Exclusive Technologies
®
NEW
4
Bandwidth of 500MHz supports resolutions up to 1080p
4
Front LEDs indicate the selected source and
input/output status
4
Optical IR, Serial IR, RS-232, Front Panel Controls,
RCA connectors
General Info
Regulation: CE, RoHS
›
Power: 100VAC to 240VAC,
›
50Hz and 60Hz
Rack Mountable 1U
›
(rack ears included)
Remote Control: Included
›
Enclosure: Black Metal
›
Dimensions:
›
17 . 5 " x 7" x 1 . 7 5"
Shipping Carton Dimensions:
›
23" x 13" x 4 . 5 "
Product Weight: 6 lbs
›
Shipping Weight: 9 lbs
›
