HDMI Switcher:
Crystal-clear switching of four (4) HDMI Inputs to One (1) HDMI Output
HDMI Type A 19-pin connector
To support DVI-D Video I/O, use HDMI<>DVI adapter cable(s)
Supports HDCP Copy Protection
Switches 60 Hz and 50Hz video sources, and multiple audio formats
HDMI repeater functionality with hot plug detection
Switches Video and Audio with individual connectors for:
HDMI Video and Audio
Toslink Optical Audio
Digital PCM Audio
Analog stereo Left & Right Audio
Can also be configured to process and scale any HDMI video input to match
the native resolution of your display:
Using world-renowned Key Digital
A full-function, high-quality Video Processor is included
Supports all popular source and display formats and resolutions
Pass-through mode (output = input)
Accepts and automatically detects 60 Hz and 50 Hz input formats (the output frame rate
will be the same as the input frame rate)
Built-in Test patterns available through the front-panel controls as well as RS-232
Easy to control and operate:
Convenient front-panel display and pushbuttons
Store your custom settings (like brightness, contrast, much more) for each of the four (4)
HDMI Inputs
Easy-to-operate IR Remote Control, and rear-panel remote input
RS-232
Firmware upgradeable
HDMI 4x1
TM
®
Clear Matrix Pro
TM
technology
Operating Instructions
Page 5 of 24
