Key Digital KD-HDMI4X1 Specifications

Video/Audio Switchers
KD-HDMI  X 1
KD-HDMIX1 is a HDMI Switcher capable of switching
 HDMI/DVID (up to 1080p) Inputs to 1 HDMI/DVID Output
Key Benefits
4
Switches up to four HDMI/DVID video sources with analog
or digital (PCM, Optical, or HDMI) audio
4
iAS (Intelligent Auto Sense) auto senses signal presence
™
and switches to active input
4
Incorporates 6 Key Digital Exclusive Technologies
®
Key Solutions
Integrates all HDMI/DVID Video/Audio sources
›
Switches between 4 HDMI/DVID inputs into 1 HDMI/DVID output
›
Compatible with all video resolutions
›
Allows push button, IR or RS-232 control for input selection
›
in addition to IAS ™ auto sense switching
Provides a one cable solution to the display and/or A/V receiver
›
Control systems supported via RS-232/IR: AMX (supports AMX DDDP – Dynamic Device
›
Discovery Protocol), Crestron, Control4, RTI, Universal, Xantech and more
18
NEW
4
Supports all digital HD and SD video standards
including 1080p/60
4
Serial IR, Optical IR, RS-232, Front Panel Controls,
Discrete Remote Codes
4
Full support for HDCP signals
General Info
Regulation: CE, RoHS
›
Power: 100VAC to 240VAC,
›
50Hz and 60Hz
Mounting Flanges
›
Remote Control: Included
›
Enclosure: Black Metal
›
Dimensions:
›
10" x 4 . 5 " x 1 . 5 "
Shipping Carton Dimensions:
›
17" x 5" x 5 . 5 "
Product Weight: 3 . 5 lbs
›
Shipping Weight: 6 lbs
›
Entertainment Venue Application
Model: KD-HDMIX1
Plasma TV
KD-HDMI4x1
front
Ir Control
Key Digital Exclusive Technologies
®
Surround Sound
Serial Ir
rS232 Control
Ir Control
back
Satellite Box
Cable Box
DVD Player
DVr Player
1
