• Easy to control and operate:
• Convenient front-panel display and pushbuttons
• vEasy-to-operate IR Remote Control
• RS-232
Video & Audio Inputs
• There are four (4) Inputs, on the rear of the product, labeled "1" through "4"
• Select "RGB" or Component (YPbPr) for each Input
• For each of the four (4) Inputs, there are the following connectors:
• HDMI A/V: 1 x HDMI Type A 19-pin connector
• Supports HDCP Copy Protection
• To support DVI-D Video, use HDMI<>DVI adapter cable(s)
• Digital Coaxial PCM Audio: 1 x RCA female
• Optical Audio: 1 x Toslink
• Analog stereo Left & Right Audio: RCA female (1 each color-coded Left & Right)
Video & Audio Outputs
• There is one (1) Output, on the rear of the product, with the following connectors:
• HDMI A/V: 1 x HDMI Type A 19-pin connector
- • Supports HDCP Copy Protection
- • To support DVI-D Video, use HDMI<>DVI adapter cable(s)
• Digital Coaxial PCM Audio: 1 x RCA female
• Optical Audio: 1 x Toslink
• Analog stereo Left & Right Audio: RCA female (1 each color-coded Left & Right)
Video Input Formats Supported
• Supports the following popular Input Formats:
• 720 x 480i @ 60 Hz
• 720 x 480p @ 60 Hz
• 1280 x 720p @ 60 Hz
• 1920 x 1080i @ 60 Hz
• Accepts and automatically detects 60 Hz and 50 Hz input formats
Video Output Formats Supported
• Supports the following popular Output Formats:
• 640 x 480p @ 60 Hz
• 720 x 480i @ 60 Hz
• 720 x 480p @ 60 Hz
• 1920 x 540 p @ 60 Hz
• 1280 x 720p @ 60 Hz
• 1368 x 768p @ 60 Hz
• 1280 x 768p @ 60 Hz
• 1400 x 1050p @ 60 Hz
• 1920 x 1080i @ 60 Hz
• 1920 x 1080p @ 60 Hz
• The output frame rate will be the same as the input frame rate, and supports 60 Hz and
50 Hz input formats
HDMI 4x1 Operating Instructions
TM
• 576i @ 50 Hz
• 576p @ 50 Hz
• 720p @ 50 Hz
• 1080i @ 50 Hz
• 576i @ 50 Hz
• 576p @ 50 Hz
• 720p @ 50 Hz
• 1080i @ 50 Hz
• Pass-through mode (output = input)
