Key Digital KD-HDMI2X8P Specifications

Video/Audio Distribution Amps
KD-HDMI 2 X 8 P
KD-HDMI2X8P is a Video/Audio HDMI switcher and distribution amplifier capable
of switching 2 HDMI/DVID (up to 1080p) Inputs and distributing Input to 8 Outputs
Key Benefits
4
Switches between two HDMI/DVID video sources with
analog or digital (PCM or HDMI) audio and distributes
to all 8 outputs
4
Supports analog, coaxial digital (PCM)
4
Supports any HDMI/DVID resolution at 50 Hz and 60 Hz
4
Decodes HDMI digital audio into Coaxial PCM digital audio
for output on white RCA L/PCM connector
Key Solutions
Switches 2 HDMI Video/Audio sources for distribution to 8 displays
›
Can be cascaded to support up to 100 outputs or displays
›
Control systems supported via RS-232/IR: AMX (supports AMX DDDP – Dynamic Device
›
Discovery Protocol), Crestron, Control4, RTI, Universal, Xantech and more

NEW
4
iAS ™ (Intelligent Auto Sense) auto senses signal presence
and switches to active input
4
LEDs indicate the selected source and
input/output status
4
Flexible EDID (Handshake) Control for any output
4
Incorporates 7 Key Digital Exclusive Technologies
®
4
Optical IR, Serial IR, RS-232, Front Panel Controls
General Info
Regulation: CE, RoHS
›
Power: 100VAC to 240VAC,
›
50Hz and 60Hz
Rack Mount: Yes - 1U
›
Remote Control: Included
›
Enclosure: Black Metal
›
Dimensions:
›
17" x 7 . 5 " x 1 . 7 5"
Shipping Carton Dimensions:
›
23" x 13" x 4 . 5 "
Product Weight: 6 lbs
›
Shipping Weight: 9 lbs
›
Retail Application
Model: KD-HDMI2X8P
Plasma/LCD
Plasma/LCD
K D
- H D
M I
X H
D M
I
K D
- H D
M I
X H
D M
I
Optical IR
Cable Box
HD DVD or
Blu-Ray
Key Digital Exclusive Technologies
®
Plasma/LCD
Plasma/LCD
Plasma/LCD
Plasma/LCD
Plasma/LCD
Plasma/LCD
RS232 Control
Serial IR
Optical IR
KD-HDMI2x8P
7
