Black Bull Series
HDMI Switchers
Operating Instructions
KD-HDRV2X1
KD-HDRV3X1
KD-HDRV4X1
Key Digital Black Bull Series
HDMI/DVI switchers are designed and engineered to offer the
™
best in quality, performance, and reliability while providing a cost effective HDMI/DVI switching
solution. The KD-HDRV2X1, KD-HDRV3X1, KD-HDRV4X1 HDMI switchers provide multiple
input to one output switching and maintain crystal-clear, pristine picture and sound quality.
Key Digital Black Bull Series
switchers are a transparent solution for all digital video/audio
™
switching applications and support all HD and SD video standards, including 1080p/60. KD-
HDRV switchers feature iAS
Intelligent Auto Sense signal detection and switching, pushbutton
™
control, IR, RS-232, status-monitoring LEDs, and support for HDMI CEC.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Key Digital Black Bull KD-HDRV2X1
Summary of Contents for Key Digital Black Bull KD-HDRV2X1
-
Page 1: Operating Instructions
Operating Instructions KD-HDRV2X1 KD-HDRV3X1 KD-HDRV4X1 Key Digital Black Bull Series HDMI/DVI switchers are designed and engineered to offer the ™ best in quality, performance, and reliability while providing a cost effective HDMI/DVI switching solution. The KD-HDRV2X1, KD-HDRV3X1, KD-HDRV4X1 HDMI switchers provide multiple input to one output switching and maintain crystal-clear, pristine picture and sound quality. -
Page 2: Quick Setup Guide
Step 6: Be sure the Operation Mode Switch is set to the “Normal” position ½ HDMI/DVI HDMI/DVI Step 7: Connect power to the KD-HDRV unit ½ Blu-Ray *To connect DVI use Key Digital HDMI to DVI adapters, part numbers KD-FMHDMI and KD-MFHDMI Step 8: Power on input/output devices ® ½ Satellite Box HDMI/DVI... -
Page 3: Table Of Contents
............Always follow the instructions provided in this Operating Manual. © 2010 Key Digital, Inc. All rights reserved. -
Page 4: Introduction
KD-HDRV switchers can also be used with DVI-D sources and displays. For these applications, use DVI to HDMI (Key Digital model number KD-MFHDMI or KD-FMHDMI) adapters. Note that while HDMI supports both video and audio over an HDMI cable, DVI-D supports only video. -
Page 5: Accessories
Page 3 Accessories External 5 Volt 1 Amp power supply ½ IR Remote Control ½ Rack Ears ½ Operating Instructions ½ Warranty Card ½ IR Receiver with 3.5 mm Male Stereo Plug ½ Installation and Operation Before permanently securing the unit for final installation of cabling behind walls or ceilings, test for proper operation of the unit and the cables in your system. -
Page 6: Ir Emitter Control
Page 4 Serial IR & IR Emitter Control The “Serial IR” port requires the use of a Male 3.5mm Mono cable (not included) with the IR ½ command signal being carried on the “Tip” of the input inserted into the KD-HDRV unit. The location of the IR signal may vary by control system used. -
Page 7: Multiple Kd-Hdrv Unit Configurations
Page 5 sir_x_x_y Addressing per x x = desired two-digit address for Command command (01 – 99) y = Input Select, Up, Down (1-4, 5, 6) Address Setting Status dir_y Delete Address Setting y = Input Select, Up, Down (1-4, 5, 6) per Command All RS-232 commands must be in lower case letters, require spaces where indicated above with ½... -
Page 8: Edid Control Settings
Page 6 EDID Control Settings At times, your HDMI sources and display may not synchronize properly. This is when EDID* control should be utilized. KD-HDRV switchers feature an internal library of default settings that modify KD-HDRV input port’s EDID to ensure that your HDMI source’s output is compatible with your display. -
Page 9: Firmware Upgrades
From time-to-time, Key Digital provides updates for the firmware that operates and controls your KD-HDRV unit. These updates are optional, and you should only perform upgrades as provided and instructed by Key Digital. Periodically check out web site at www.keydigital.com for the latest firmware updates for your unit. -
Page 10: Mechanical / Technical Specifications
Page 8 Mechanical / Technical Specifications 4/3/2 HDMI Connectors Inputs Outputs 1 HDMI Connector Bandwidth TMDS bandwidth 10.2 Gb/s Compliance With Supports HDMI1.3+, HDMI1.2, HDMI1. 1 , DVI1. 1 and HDCP . HDMI Standard Link Single Link: 1080p/60, 12 bit color depth, 1920x1200 max. Deep Color Support Supports digital video formats in Deep Color Mode at up to 12 bits/color... -
Page 11: How To Contact Key Digital
® Phone: 914-667-9700 ½ E-mail: tech@keydigital.com ½ Repairs and Warranty Service Should your product require warranty service or repair, please obtain a Key Digital Return Material ® Authorization (RMA) number by contacting us at: Phone: 914-667-9700 ½ E-mail: rma@keydigital.com ½... - Page 12 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
