Celia Air Tight Plus
Celia Air Tight Plus C
PELLET STOVE
For all updates visit www.edilkamin.com
EN
Installation, use and maintenance
page 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Celia Air Tight Plus and is the answer not in the manual?

Questions and answers

Related Manuals for EdilKamin Celia Air Tight Plus

Summary of Contents for EdilKamin Celia Air Tight Plus

  • Page 1 Celia Air Tight Plus Celia Air Tight Plus C PELLET STOVE For all updates visit www.edilkamin.com Installation, use and maintenance page 2...
  • Page 2 CELIA AIR TIGHT PLUS C/ CELIA AIR TIGHT PLUS Performance declaration (DoP - EK n° 192) Moreover, the company hereby declares that: the CELIA AIR TIGHT PLUS C/ CELIA AIR TIGHT PLUS wood pellet stoves satisfy the requirements of the following European directives:...

  • Page 3: Meaning Of Symbols

    If you lose it, • the declaration of conformity given to you by the installer. you can request a copy from your dealer or download it from www.edilkamin.com. The warranty conditions are given in the warranty certificate accompanying the product.

  • Page 4: Safety Information

    DO NOT BLOCK refer to the warranty certificate inside the THE AERATION VENTS OR FLUE. Risk product: specifically, neither Edilkamin nor of smoke returning into the room with the retailer are liable for damage resulting consequent damage and injury.
  • Page 5 DIMENSIONS (cm) Celia Air Tight Plus Ø 8 cm smoke outlet Ø 6 cm air intake 18,5 Ø 6 cm ducting Celia Air Tight Plus C Ø 8 cm smoke outlet Ø 13 cm coaxial 18,5 Ø 6 cm ducting USER/INSTALLER...

  • Page 6: Technical Data

    Stand by absorption Power Absorbed power on ignition 365 W Remote control frequency (provided) 2,4 GHz Protection rating Fuse 4 AT, 250 Vac 5x20 EDILKAMIN s.p.a. Reserves the right to modify the product without notification in the inte- rests of improvement. USER/INSTALLER...

  • Page 7: Unpacking And Preparation

    The product is supplied with the deflector not installed: insert it as shown in the figure. The deflector is a component subject to wear. Neither Edilkamin nor the dealer shall be held liable should this component break, all the more if it breaks accidentally during handling operations.
  • Page 8 UNPACKING Stoves are delivered with the coatings fitted. Unscrew and remove them from the top to take the stove off from the pallet. DO NOT REMOVE THE PRODUCT FROM THE PALLET BEFORE OPENING THE DOOR AND LOOSENING THE SCREWS. THE DRAWINGS ARE FOR GUIDANCE ONLY, USEFUL FOR THE INSTALLATION, BUT THEY MAY NOT REFER TO THE SPECIFIC MODEL.

  • Page 9: Installation

    • The room must have a volume of at least 30 m Contact the authorised Edilkamin Technical Assistance • The floor must be able to bear the weight of the Centre. product and its accessories* (see the note in the paragraph on the heat protection) •...
  • Page 10 INSTALLATION INSTRUCTIONS INSTRUCTIONS SMOKE SMOKE THE FUMES DUCT THE FUMES DUCT DISCHARGE DISCHARGE WITH WITH WITHOUT WITHOUT • Further to the general prescriptions for the fumes CONCENTRIC PIPE CONCENTRIC PIPE duct and flue, the fumes duct: • may not be made of flexible metal material •...
  • Page 11 INSTALLATION INTUBATED SYSTEM INTUBATED SYSTEM: Further to the general prescriptions for the fumes duct and flue, the intubated system: • must operate in negative pressure; • must be open to inspection; • must observe local regulations. THE CHIMNEY POT THE CHIMNEY POT (In every country and specially in France, check on the specific waiver conditions) •...

  • Page 12: Combustion Air Intake

    INSTALLATION COMBUSTION AIR INTAKE USE OF CONCENTRIC PIPES USE OF CONCENTRIC PIPES The inflow of necessary air for combustion, of air for Without prejudice to the general instructions, you can glass cleaning and heating air renewal must come use concentric pipes (which provide for the passage of from the outside smoke inside and the passage of the combustion air into the external circular ring).

  • Page 13: Checking The Electrical Connections

    The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.
  • Page 14 INSTALLATION DUCTING OF HEATING AIR DUCTING OF HEATING AIR To duct the warm air exiting the rear (protected as standard by a grille), you will find several optional extras at your reseller: • air duct pipe (3 metres, 6 cm diameter) •...

  • Page 15: Pellet Loading

    USER INSTRUCTIONS FIRST IGNITION (COMMISSIONING) PHASES PELLET LOADING • Make sure you have read and understood this Gently slide the top until the end stop to load pellet. manual Open the inner hatch and just pour pellet making sure • Remove all flammable materials from the appliance not to spill it out (manuals, labels, etc.).

  • Page 16: Operation

    USER INSTRUCTIONS OPERATION The product also has the following supplementary Mode Settable parameters functions. MANUAL • power level • ventilation level (if there are Function Modes in which What it does two or more fans, they can be it can be acti- adjusted separately)* vated AUTOMATIC...
  • Page 17 USER INSTRUCTIONS INTERFACE The product can be managed alternatively as follows STANDARD • Bluetooth REMOTE CONTROL: can be used By purchasing the Edilkamin optional elements: for all functions, near the product • VOICE CONTROL SYSTEMS: Alexa or Google Home •...

  • Page 18: Optional Electrical Connections

    OPTIONAL THERMOSTATS/PROBES CONNECTIONS OPTIONAL ELECTRICAL CONNECTIONS NOTE: The connections must be made by qualified On the product (accessible by removing the coating, personnel, with the electricity disconnected. with the electricity off and only by qualified technicians) a dedicated low voltage terminal block can be found More info for installers on the site.
  • Page 19 This only refers to the remote control, not the product itself. In normal use, the remote control's batteries should last a year. This duration is for illustrative purposes only. Edilkamin and the reseller will not consider claims for battery life under any circumstances. RELAX WALL...
  • Page 20 INSTRUCTIONS FOR USE: REMOTE CONTROL Current room temperature Target room temperature Bluetooth communication present between the product and the PCB. If there is no communication, the symbol disappears. On only if the battery is running out. Maintenance necessary symbol. Appears after a certain number of hours of operation. In some models the symbol may be linked to a fuse problem on the board.
  • Page 21 INSTRUCTIONS FOR USE: REMOTE CONTROL Visualisation of the status of the fan(s). If the product has not heated up, no symbol will ap- pear. FAN OFF: SPEED 1 SPEED 2 SPEED 3 SPEED 4 SPEED 5 AUTOMATIC Indicates that the product has switched off after the Bottom bar for target has been reached with stand-by mode active.

  • Page 22: Power On/Power Off

    USER INSTRUCTIONS POWER ON/POWER OFF These operations will take a few minutes, during which the flame must appear or extinguish. Simply wait without taking any action. The ON/OFF button is used to manually start the on or off phase. During the switch-on, the display will show the status (CLEANING;...
  • Page 23 USER INSTRUCTIONS AUTOMATIC and MANUAL setting AUTOMATIC MANUAL Press the AUTO/MAN button to switch from manual to automatic mode or conversely. In AUTOMATIC mode: Example: press a button and activate the display, Setting the room temperature (read by the then press the button remote control, which should be in the room where the product is installed).

  • Page 24: Fan Adjustment

    USER INSTRUCTIONS - FAN ADJUSTMENT The setting can be made with the stove turned OFF or ON. If the backlight is switched off, it can be activated by pressing any button. Then by pressing the button SET flashes and instead of the environment Set, the indication of the number of the fan being edited appears (F1).

  • Page 25: Relax Function

    USER INSTRUCTIONS - RELAX FUNCTION Natural convection function (without ventilation) with automatic power limiting. This function is available in all modes: automatic, manual and crono. Press the button to activate the Relax function. Its activation on the display will be signalled by the arrow relative to the Relax button Again by prolonged pressing of the button, the...
  • Page 26 USER INSTRUCTIONS - EASY TIMER FUNCTION (delayed switching off and on) This function switches the product on/off after a set period from activation of the function. This is convenient if you go to bed and want the product to switch on/off after a few hours (maximum 12 hours).
  • Page 27 USER INSTRUCTIONS CRONO After setting the times, temperatures or power levels in the CRONO MENU, if the prod- uct is in automatic mode, the timer will work at room temperature, otherwise at the power setting. Pressing the button allows for switching from Crono in Temperature and Crono to Power and vice versa.
  • Page 28 USER INSTRUCTIONS - MENU It can be accessed by pressing the button and the first Menu item will appear. You can scroll the menu items with the buttons, and enter the item with the button The menu items appear in the following order: NOTE STAND-BY Depending on the version, the order of the items may...
  • Page 29 USER INSTRUCTIONS STAND-BY When the Stand-by function is active, in the automatic and crono modes, the product switches off once the temperature set-point is reached and turns on again when the room temperature drops below the chosen value. When the Stand-by function is not active, the product sets itself to minimum power when the temperature set- point is reached.
  • Page 30 USER INSTRUCTIONS PELLET LOADING Allows you to load pellets after the pellet tank has been completely emptied. Useful for the technician during the initial start-up. Available only in the OFF status. Any attempt to activate the function in other statuses will not be allowed. To access the function from the main menu (as indicated in the Menu section above), press the MENU button.
  • Page 31 USER INSTRUCTIONS Choose the day of the week by scrolling the buttons (you will simultaneously see the programme for that day) and confirm with the button. The cursor (rectangular) positions itself on 00:00. OK SAVE BUTTON The time at the top RH shows the start of the time slot Use the buttons to scroll the time with 1/2-hour steps, by moving the cursor and displaying...
  • Page 32 USER INSTRUCTIONS buttons can be used to modify the temperature levels (OFF – T1 and T2) or the power levels (OFF – P1 and P5). After reaching 23:30 you must go backwards. If you shift by pressing and holding the buttons for more than 2”, you copy the previous level onto the next level with a 1/2 h frequency per second.
  • Page 33 USER INSTRUCTIONS The copied day of the week flashes and you can shift to the next day using the buttons Confirm with the button Briefly pressing the button allows you to exit the programming mode, but the programme will not activate.
  • Page 34 USER INSTRUCTIONS TEMP. CRONO (T1-T2) Temperature setting for timer T1 – T2 To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons, and enter the item with the button After entering the T1-T2 function, the display will show the name of the function on the first line of the status bar...
  • Page 35 USER INSTRUCTIONS DATE-HOUR Can be used to set the current date and time. To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons, and enter the item with the button After entering the Date-Time function, the display will...
  • Page 36 USER INSTRUCTIONS LANGUAGE Selects the language. To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons, and enter the item with the button After entering the Language Menu item, the name of the function appears on the first line of the status bar and...
  • Page 37 USER INSTRUCTIONS DISPLAY Allows you to change the brightness of the display and an acoustic signal when the keys are pressed BRIGHTNESS ON Indicates the backlight percentage of the display. You can switch from one percentage to the other with buttons + and - and confirm with OK button STBY BRIGHTNESS Indicates the backlight percentage of the display be-...
  • Page 38 USER INSTRUCTIONS INFO These readings should only be done when requested by the technician. The technician understands the diagnostic meaning of the messages and values, and may ask you to read them to him/her if you experience problems. To access the function from the main menu (as indicated in the Menu section above), press the MENU button.
  • Page 39 USER INSTRUCTIONS - INFO (info for INSTALLER continues) They provide instant situation values. Flue temperature indicates the value of the temperature read inside the product. To be read only under the guidance of the Technical Assistance Centre Auger motor: indicates the speed set and read.
  • Page 40 USER INSTRUCTIONS - SOFTWARE Indicates: • the firmware version of the electronic board (basic board) • the firmware version of the control panel • the database (associated by the Technical Assistance Centres with the products) To be read only under the guidance of the Technical Assistance Centre INSTALLER...
  • Page 41 USER INSTRUCTIONS DATA Information of the product’s operation log can be scrolled with the buttons To access the function from the main menu (as indicated in the Menu section above), press the MENU button. You can scroll the menu items with the buttons, and enter the item with the button DATA...
  • Page 42 USER INSTRUCTIONS ALARMS Information of the product’s operation log can be scrolled with the buttons. Readings to be carried out under the guidance of a technician. The meaning of the abbreviations is in the dedicated paragraph The alarms are arranged from the most recent to the oldest. Exit with the button PELLET FALL Allows to set the auger motor in continuous cycle or in...
  • Page 43 USER INSTRUCTIONS TECHNICAL MENU (for TECHNICIANS ONLY) Accessible only by technicians with password (1111). Once the password has been entered, confirm with the button If you enter with the installer password (1111) you will NOTES only access the following installer parameters/settings: inappropriate changes can cause the product to seize up - FLAME TYPE...
  • Page 44 USER INSTRUCTIONS - PELLET TYPE You can scroll the Technical Menu items with the buttons until you reach “PELLET TYPE” Enter the Pellet Type (%) setting with button the value can be modified with button Use the button to exit and return to the Technical Menu In correct installation conditions, with the Service Centre parameters appropriately adjusted, with quality pellets, the pellet load is adjusted...
  • Page 45 USER INSTRUCTIONS - PARAMETERS Scroll through the items of the Technician Menu with buttons up to the item “PARAMETERS”. You enter the Parameters with button , the first parameter is displayed. Scroll through the parameters with and the value can be modified with buttons If you entered the Technician Menu with the Installer Password, only the Installer parameters appear, otherwise all the parameters appear.
  • Page 46 USER INSTRUCTIONS PARAMETERS (continue PARAMETERS for INSTALLER) SENS. PLT LEVEL: enables or disables the CRONO SYNCHR.: synchronises the possibility for the end customer to view and timer choose the status of the pellet reserve indicator UNPAIR BLUETOOTH: enable AIRKARE FUNCTION: allows to select IF Airkare is active and on which room size (SMALL, less than 30 m , or BIG) or not active...

  • Page 47: Save Panel

    USER INSTRUCTIONS: SAVE PANEL SAVE PANEL network present “power” button O n - O f f button SAVE PANEL can temporarily make up for the absence of a remote control or smartphone, or other product management systems. Controls the product starting from the pressing of the buttons. When the remote control or smartphone re-establishes the communication and sends a command to the product, the remote control or smartphone will once again resume control of the product.
  • Page 48 USER INSTRUCTIONS: SAVE PANEL The three LEDs on the left indicate the status of the product associated with the display. Panel without control unit Active: LED1 (network present) Stove off Digits = “OFF” active: LED1 Stove being switched on Digits = “ON” active: LED1 and LED2 Stove running Digits = “ON”...

  • Page 49: Daily Maintenance

    MAINTENANCE Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance is essential to keep the appliance in good working order. Failure to service the product properly will prevent it from working properly. Any problems due to failure to service the stove will void the warranty. DAILY MAINTENANCE These jobs should be done with the product off, cold and preferably disconnected from the mains.
  • Page 50 MAINTENANCE 1. Open the combustion chamber door using the removable handle provided. 2. The burning pot slips into position in its housing. Empty the ash tray and burning pot into a non-flammable container (the ashes may still contain embers and/or hot parts) or vacuum if cold. Vacuum out the interior of the combustion chamber, the bed, and the compartment around the burning pot into which the ash falls.

  • Page 51: Seasonal Maintenance

    For any spare parts, contact your dealer or technician. flue every 3 months. Using non-original spare parts may damage the appliance and relieves Edilkamin of all liability for You should clean the chimney system at least once a damage resulting such use.

  • Page 52: Troubleshooting

    TROUBLESHOOTING In case of an alarm, an alarm code will appear instead of the room temperature. While the product switches off, the status bar will alternately show “OFF” in large letters and the description of the alarm in small letters. If the alarm occurred with the timer active, only the timer’s activation arrow will remain displayed, while the day’s time schedule will disappear.
  • Page 53 TROUBLESHOOTING MESSAGE PROBLEM SOLUTION • Check that the combustion chamber door is closed displays when the combustion • Check the regular maintenance of the product air intake is below the set level • Check that smoke discharge and combustion air ducts are clean.
  • Page 54 TROUBLESHOOTING MESSAGE PROBLEM SOLUTION Room temperature probe failure. The product is operating • Contact the technician in manual mode. Ducting room temperature probe (if present) fault. The • Contact the technician product is operating in manual mode. Ducting room temperature probe (if present) fault.
  • Page 55 MAINTENANCE: A spanner symbol will appear on the display after 2,000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician. LACK OF COMMUNICATION: In case of a prolonged lack of communication between the stove and the remote control, the Bluetooth transmission icon will disappear as well as the icons transmitted by the circuit board to the remote control.
  • Page 56 TROUBLESHOOTING PELLETS RESERVE INDICATOR: The function is only available if the pellet level sensor is installed and has been activated. When the level sensor intervenes, the circuit board emits a single “beep” (in any switch-on or work status) and the moving reserve symbol will appear on the display.
  • Page 57 TROUBLESHOOTING After an interval of roughly 20/30 minutes, which varies depending on the model, the stove switches off due to a shortage of pellets. If the user reloads the stove before the start of the switch-off procedure, the symbol disappears and the stove resumes its normal operation.
  • Page 60 *942163-GB* w w w . e d i l k a m i n . c o m cod. 942163-GB 07.22/B...
