SP Series User Manual
1、 Introduction
SP series is developed by Shenzhen Center Power Tech Co.,Ltd., which is suitable for
backup purpose of
UPS ,energy storage system and Recreational Vehicle.
BMS is built into the battery system, which is responsible for collecting and analyzing the
voltage, temperature and current of the single cell. It has the functions of over-voltage
protection, under-voltage protection, high temperature protection, low temperature
protection, short circuit protection and cell balance.
2、Overview
Model
Nominal Voltage
Capacity
Cell
3.2V-1500mAh
Cells Grouping
3. Dimension：
SPH12-6
VISION GROUP
Shen Zhen Center Power Tech Co.,Ltd
SPH12-6
SP12-100A
6Ah
100Ah
3.2V-100Ah
4S4P
4S1P
www.vision-batt.com
/
Page 1/6
Updated: Mar 2021
SP12-100
SP12-150
12.8V
100Ah
150Ah
3.2V-100Ah
3.2V-50Ah
4S1P
4S3P
SP12-100A
A
SP12-200
200Ah
3.2V-100Ah
4S2P
