- Page 1 WWW.GVISION-USA.COM PVM24ZJ-OC3-4 USER’S MANUAL IP PUBLIC VIEW MONITOR GVISION USA, INC 30398 Esperanza, Rancho Santa Margarita CA 92688 / 949.586.3338 / info@gvision-usa.com...
- Page 2 CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this equipment, please contact GVISION. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located.
- Page 3 Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 4: Table Of Contents
Setup Under SD/ USB Input Mode……………………………………………………………......19 Care & Cleaning………………………………………………………………………………………………………19 10. Mounting Monitor on Wall…………………………………………………………………………………………..19 11. Camera Management………………………………………………………………………………......19 12. Specifications………………………………………………………………………………........20 13. Dimensions……………………………………………………………………………………………………………..21 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 5: Accessories
CVBS recording system. The CVBS output May not be available for some models. Connect device with a VGA output 15 pin D-sub cable Power input DC24V, 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 6: Control & Functions
Press SOURCE button to enter the sub-menu，then press ＋／－button correspondingly to change the setting When the setting is done, press MENU button to return to the previous menu or exit 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 7: Remote Control
Volume Down / Select Left Confirm Selection ► Volume Up / Select Right Exit Exit ►II Play / Pause Confirm Selection ■ Exit / Stop 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 8: Input Source
PVM Image mode>Motion. The PVM can also auto switch between different channel based on time, pls refer to the Image Mode setting>Switch 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 9: Osd Setup Under Av/ Hdmi Input Mode
Press the “< or >“, button to select five kinds of settings (Low, Middle, Noise Reduction High, Off and Default), then press “Menu” button to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... - Page 10 Press “< or >” button to select ”On or Off”, Then , press “Menu” button Mute to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 11 Press “< or >” button to set backlight. You have three sections: “ High, Backlight “Menu” button to exit. Middle and Low”. Finally, press 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 12 Press “< or >” button to set the size of horizontal/ Vertical over-scan. H/V-Size Finally, press “Menu” button to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 13 And there are four modes in message select. And you could set on/off Special Control in the message flicker and led flicker. Finally, press “Menu” button to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 14: Osd Setup Under Vga Input Mode
“<or>“button to select “ 4:3 or Full” . Finally, press “Menu” button to exit Noise Reduction N/A. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... - Page 15 Finally, press “Menu” button to exit Press “< or >” button to select ”On or Off”, Then , press “Menu” button Mute to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 16 Press “< or >” button to set backlight. You have three sections: “ High, Backlight “Menu” button to exit. Middle and Low”. Finally, press 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 17 Press “< or >” button to change the figure (from 0 to 100), Then press Phase menu to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
- Page 18 And there are four modes in message “RECORDING IN PROGRESS” or Special Ctrl “WELCOME”. And you could set on/off in the message flicker and led flicker. And press “Menu” button to exit. 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
-
Page 19: Setup Under Sd/ Usb Input Mode
Pls log into the IP camera via web or the VMS software in the CD, the default IP address is Dynamic, and User name: admin / Password: admin 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 20: Specifications
DC24V (AC 100V ~ 240V, 50/60Hz) TEMPERATURE Operating 0~50°C VESA™ Mount Size 100 x 100mm Specifications subject to change without any notice 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ... -
Page 21: Dimensions
WWW.GVISION-USA.COM Dimensions 30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com ...
