84 | Vocollect Talkman A700 Product Guide

Visual Training Devices

• Visual training devices enable operators to read the words that they need to say during the enrollment
training process.
• Vocollect recommends using a browser-based mobile display with Talkman A500 or A700 devices, and
the QTERM-G55 with Talkman T5 or T2x devices.
• These devices have a liquid-crystal screen that displays words that an operator needs to train. Operators
are more likely to speak in their normal conversational tone when reading the words than when hearing
the device say the words during training.
• Vocollect provides a cable with a connector so that the QTERM device can be attached to the red port on
the device.
• Supporting documentation and software for the QTERM visual training device is available for free download
on the manufacturer's website. Please refer to this site for all supplemental product information such as
the user manual, specifications, data sheet, tutorials, and accompanying software.
Note: In order to use QTERM devices with a Thai TTS, you must use a QTERM-G55 running device
software version 3.1 or newer. After connecting the QTERM, verify you have the correct software by
checking debug logs for the message "TRAIN DEVICE: Device query detected training device G55
using v3.1." If you do not see this message, you do not have the correct software, and you must obtain
it to use the device with a Thai TTS.

Setting Up the QTERM Visual Training Device

1. Verify that the training device is set up properly. Refer to the instructions that QSI or your reseller provided
with the training device for more information.
2. Connect the training device to the device using the cable provided.
3. In the task name.vcf file, set the configurable parameter TrainDevicePort = Red to turn on the training
device port.
4. Reload the task onto the device.
If the training device does not work after a task load, power the Talkman device off, then power it on again.

Configuring the QTERM Visual Training Device

Note: You cannot change the default baud rate for the QTERM training device setting of 9600 for versions
of VoiceClient 1.x or 3.x.
1. Verify that the task is loaded onto the device.
2. Verify that the device is sleeping.
3. Verify that the training device is connected to the device.
Confidential: For informational use by Honeywell resellers and customers only
Figure 20: Pidion BM-170 and QTERM-G55
