Bending radius of heated sampling lines

The picture below shows the minimal bending radius.

15.7. Spare parts

Part number
56879A
61158
61157
10825
59799
61066
61333
60074
116 / 118
User Manual VARIOluxx Syngas
Bending radius min. = 32 cm
Falling below the bending radius will reduce life time of the sam-
pling probe.
ATTENTION
Spare part
PTFE Round filter
Probe filter sintered metal 2 μm
Probe filter sintered metal 20 μm
Mineral wool filter element
O-Ring 16 x 1,5
O-Ring 12 x 2
O-Ring 10 x 2
O-Ring 8 x 2
MRU GmbH, D-74172 Neckarsulm
