CHECK INSTALLATION HARDWARE

Locate the hardware package packed with the hood and check contents.
HARDWARE PACKAGE
Locate and count screws
4 Duct cover clips
73 Hood attachment screws
Cut one 1/2" Dia.
Wire Access Hole
as Needed
8-1/4" To
Centerline of
Pilot Holes
Cut one 1/2" Dia.
Wire Access Hole
as Needed
RECIRCULATING KIT (Included)
Air deflector
Installation Preparation
4 Wood
screws
(70 required, 3 extra)
Drill 3/16" Pilot Holes
Approx. 1-1/2" Deep
4 Places
10-5/16" To
Centerline of
Cut one 1/2" Dia.
Pilot Holes
Wire Access Hole
as Needed
36" HOOD
TEMPLATE
8-1/4" To
Centerline of
Pilot Holes
Cut one 1/2" Dia.
10-5/16" To Wire Access Hole
Centerline of as Needed
Pilot Holes
FRONT OF HOOD
31-14772
Printed in Mexico 12-08 JR
Template
C
B
Stainless steel filter
Upper
Duct covers
Charcoal filter
11
A
D
Upper vertical supports (4)
A
B
E
Lower vertical supports (4)
C
Duct cover supports (2)
D
Ceiling support
E
Horizontal support
Lower
