CHECK INSTALLATION HARDWARE
Locate the hardware package packed with the hood and check contents.
HARDWARE PACKAGE
Locate and count
4 wall fasteners
(screw with
6 wood screws
wall anchor)
(#10 1-3/4" long)
WALL VENT IS 27-3/4" MIN.
DRILL 2 (TWO) 3/16" PILOT HOLES THROUGH STUDS OR REAR WALL SUPPORT
ABOVE THE INSTALLATION
HEIGHT
DRILL 2 (TWO) 3/16" PILOT HOLES THROUGH STUDS OR REAR WALL SUPPORT
Horizontal Line
Wall mount template
RECIRCULATING KIT (Included)
Installation Preparation
screws
8 duct cover
and air deflector
screws
(#8 thread forming
(5/16")
screw 3/8" long)
10-1/8"
REAR WALL
MOUNTING TEMPLATE
C L
ALIGN BOTTOM EDGE
WITH PENCIL LINE
INDICATING BOTTOM
OF THE HOOD
12-1/2"
Installation Height
31-14772 Printed in Mexico
Air deflector
12-08 JR
12
Stainless steel filter
Duct cover bracket
2-piece decorative
duct cover
Charcoal filter
