White 40" x 24" Electric Desk
Instruction Manual
SKU: DESK-EP40TW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-ep40tb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo DESK-EP40TW
Summary of Contents for Vivo DESK-EP40TW
- Page 1 White 40" x 24" Electric Desk Instruction Manual SKU: DESK-EP40TW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-ep40tb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Electrical Safety Instructions
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 176lbs Failure to do so may result in serious injury. (80kg) Level Phillips Drill Screwdriver... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Leg Motor (I) to Left Leg (E) using M5x12mm Screws (S-E) and 4mm Allen Wrench (T-B). Mount Crossbar (B) to Left Leg (E) and Right Leg (F) using M8x37mm Screws (S-A) and 5mm Allen Wrench (T-C). STEP 2 Place Feet (G) on top of Left Leg (E) and Right Leg (F) and attach using M6x30mm Screws (S-C) and 5mm Allen Wrench (T-C). - Page 5 STEP 3 Assemble Side Brackets (C) to the frame assembly using M6x10mm Screws (S-B) and 4mm Allen Wrench (T-B). STEP 4 Loosen the nut on Sync Rod (D). Insert the hex shaft on Sync Rod (D) into Right Leg (F). Insert the other end of Sync Rod (D) into the slot on Leg Motor...
- Page 6 STEP 5 Assemble both halves of Desktop (A) using Connecting Plates (H) with ST5x16mm Screws (S-D) and a Phillips screwdriver. STEP 6 Place the frame assembly upside down on top of Desktop (A) with Control Panel (K) and secure both using M5x16mm Screws (S-D) and a Phillips screwdriver.
- Page 7 STEP 7 Connect the AC Adapter (J) and Leg Motor (I) to Control Panel (K), then plug AC Adapter (J) into a wall outlet to power on the desk for operation. Organize cables using the Cable Clips (M). Press and hold the up or down arrows on Control Panel (K) until the desk reaches the desired height.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
