Summary of Contents for Fujitsu FD-1100MT
- Page 1 Preliminary Ver.0.50 SERVIS Drawer 17inch [FD-1100MT] NC14010-B452/xx User's Manual...
- Page 2 Interference by Information Technology Equipment). If you use this product in a domestic environment, it may cause radio interference, in which case the user may be held responsible for the cost of any required corrective action.VCCI-A All Rights Reserved, Copyright© FUJITSU LIMITED 2005 Contents...
-
Page 3: Table Of Contents
1. Preface ................... 1 1.1 Conventions ......................... 1 1.2 Packing List .......................... 1 2. Important Notices ..............2 2.1 Safety ........................... 3 2.2 Moving Console Drawer ....................... 4 2.3 Disposal..........................4 2.4 Safety Precautions and Limited Warranty Information............4 3. Installation ................6 3.1 Installing the Console Drawer (procedure for tapped guide rails) ......... - Page 4 8. Technical Specifications ............27 9. Optional Accessories (Sold separately) ....... 29 9.1 Optional Cables ........................29 9.2 Optional Guide rails ......................29 10. Troubleshooting..............30 10.1 No image displayed on monitor ..................30 10.2 Monitor display is strange....................30 10.3 Monitor cannot be adjusted ....................
-
Page 5: Preface
They may be required when moving it to another location. If something is missing from the package, contact your place of purchase or a Fujitsu sales person. Similarly, as they will be needed when the 4-port KVM switch is installed, the 4-port KVM... -
Page 6: Important Notices
Please note the safety information in [Important Notices]. CAUTION 1. Unpack the Console Drawer and check that it has not been damaged in transit. 2. Remove the rubber stabilizer from the front left side of the Console Drawer. The rubber stabilizer is inserted to prevent the Console Drawer from sliding when installing or moving it. -
Page 7: Safety
This device conforms to the safety regulations related to information processing equipment such as electronic office machines that are used in an office environment. If you have any questions please contact your place of purchase or a Fujitsu sales person. To prevent extreme bumping, shaking, vibration while moving the Console Drawer, please use the original shipping container or a similar box, in addition make sure if it fits well to the product for protection. -
Page 8: Moving Console Drawer
Product without securing sufficient safety required for such High Safety Required Use. Purchaser and its customers using or selling Products for use in such applications do so at their own risk and agree to fully indemnify Fujitsu for any damages resulting in such improper use or sale. - Page 9 Product that was defective at the time delivered to Purchaser, provided that Fujitsu will not be liable under this warranty unless: (i) Fujitsu is promptly notified in writing upon the discovery of defects by Purchaser; (ii) the defective unit is returned to Authorized Company, transportation charges prepaid by Purchaser;...
-
Page 10: Installation
3. Installation CAUTION Please note the safety information in [Important Notices]. 3.1 Installing the Console Drawer (procedure for tapped guide rails) Observe the specified environmental conditions when using the Console Drawer (See [Technical Specifications] for more information). CAUTION Avoid dust, humidity and extreme temperatures. Installation may require two or more people in some situations. - Page 11 Rear Spacer Screws Guide Rail Front Spacer Rear Spacer Studs Guide Rear Spacer Screws Guide Rail Front Spacer Front Spacer Rear Rack Pillar Front Rack Pillar Installing the Guide Rails...
- Page 12 Slide the Console Drawer into the front end of the guide rails. Be careful that the latch lever does not come loose. If the latch lever comes loose the Console Drawer may slip. If the Console Drawer doe not slide easily into the guide rail or is too heavy, get one or more other people to help yo u lift and insert it.
-
Page 13: Installing The 4-Port Kvm Switch
3.3 Installing the 4-port KVM Switch If you don't have a 4-port KVM Switch, please skip this section and go to the section for [Connecting and Removing the Cables]. Refer to [Connecting to Ports] for the connection in general. In details, refer to the original manual for the 4-port KVM switch. - Page 14 4-port KVM Switch Rubber Feet Rubber Feet Rear Panel Open Space Rear Plate Comp DC5V OUTPUT Screws DC Cable Screws Note) Make sure rubber feet to be removed in adv ance. Installing the 4-port KVM Switch...
-
Page 15: Connecting And Removing Cables
4. Connecting and Removing Cables 4.1 Connecting the Cables 1. Unplug all power cables, connected to related devices, from the power outlets. 2. Console Drawer I/F cable: 3 types subject to usage, One end for all cables are DVI The other end: PS/2 I/F cable (D-SUB, 2 Mini-DIN:6-pin PS/2 CNs), USB I/F cable (D-SUB, USB CNs), Sun I/O I/F cable (D-Sub, 1 Mini-DIN:8-pin CN) Connect the keyboard cable, mouse cable, and monitor cable to their respective ports. -
Page 16: Connecting To Multiple Servers
5. Connecting to Multiple Servers (with a 4-port KVM Switch installed in the back of the Console Drawer.) See cautions given in [Connecting and Removing the Cables] when CAUTION connecting and disconnecting ports. Also, cut the power of any affected equipment before you start working on it. -
Page 17: Operation
6. Operation Pull the Console Drawer slowly toward you until the slide rails lock. CAUTION If the slide rails are not locked, the Console Drawer can move unexpectedly. If they do not lock, the weight of the Console Drawer or any person leaning on the Console Drawer may cause it to move suddenly, and it may cause injury or damage to the product Be careful not to pinch your fingers when pulling or pushing on the slide... - Page 18 Guide Rail Cable Duct Slide Rail Console Drawer Latch Lever Handle Guide Rail LCD Lock Slide Rail Lock Spring Latch Lever Rubber Stabilizer Pulling out the slide module...
- Page 19 Push up on the LCD lock behind the handle, and then grasp the handle and open the monitor by lifting it up. Turn on the power by pushing the POWER button. Open the monitor completely. Handle LCD Lock Slide Rail Monitor(LCD) Monitor Power Button Hot-key Button...
-
Page 20: Adjusting The Monitor
6.2 Adjusting the Monitor The five buttons and one LED on the monitor are in order: Power Power Button Button Button Lamp Button Button Power Lamp: This lights blue when the power to the monitor is on, lights orange when the monitor is in energy-saving mode, and goes out when the power to the backlight is off. -
Page 21: Basic Adjustment Procedure
6.3 Basic Adjustment Procedure The basic adjustment procedure is as follows: Some main menu items do not have associated sub-menus, in which case the adjustment screen appears when the item is selected. If the AUTO/EXIT button is pressed at this phase, the screen returns to the main menu and any adjustment to setting will not be saved. -
Page 22: Main Menu Items
6.4 Main Menu Items Symbol Item Function BRIGHTNESS Adjusts the screen brightness. CONTRAST Adjusts the screen contrast. COLOR Adjusts the screen color. Fixed values or individual color tones (red, green, blue) can be set. Adjusts the display position (horizontal ). H POSITION Adjusts the display position (vertical). -
Page 23: Resolutions And Refresh Rates
6.5 Resolutions and Refresh Rates Horizontal frequency Vertical frequency Resolution Mode (kHz) (Hz) 640 x 400 31.5 VGA 400 LINE 31.5 VGA Standard 640 x 480 37.5 37.9 720 x 400 31.5 35.2 37.9 800 x 600 46.9 48.1 VESA 48.4 56.5 1024 x 768... -
Page 24: Keyboard Operation
6.7 Keyboard Operation By making use of the Function ( Fn ) key, if is possible to obtain full keyboard functionality from even a reduced space keyboard. Fn key+ key combinations: The extra command keys that are enclosed in billets (e.g. Help ) around the perimeter of the keyboard may be accessed by pressing the associated key together with the Function key (e.g. - Page 25 Fig Japanese Keyboard Example of usage: Help = Fn + Esc...
-
Page 26: Pointing Device Operation
6.8 Pointing Device Operation Lightly touch or tap the touchpad surface to operate the pointing device. Moving the pointer: Lightly slide a finger over the touchpad surface in the direction you want the cursor to move. Single click: Lightly tap the touchpad surface once, or press the left button once. Double click: Lightly tap the touchpad surface twice, or press the left button twice in succession. -
Page 27: Hot-Key And Reset Buttons
6.9 Hot-key and Reset Buttons Hot-key Scroll Caps Reset Lock Lock Lock Hot-key Button Reset Button Hot-key Button Outputs the [Ctrl] + [Alt] + [Shift] key Make/Break code. This will also be the Hot-key mode if a 4-port KVM switch is connected. Reset Button Resets the keyboard and pointing device. -
Page 28: Stowing Console Drawer
6.11 Stowing Console Drawer The Console Drawer should be stowed away in the rack when the monitor and keyboard are not in use. Slide the Console Drawer in and out of the rack slowly. 1. Push the monitor power button to turn off the power to the monitor. 2. -
Page 29: Cleaning The Console Drawer
Guide Rail Slide Rail Console Drawer Latch Lever Guide Rail Cable Duct Handle LCD Lock Latch Lever Slide Rail Lock Spring Stowing the Console Drawer 7. Cleaning the Console Drawer... - Page 30 Turn off the power and unplug the power cable from the power socket. CAUTION Do not use cleansers that contain abrasives, or organic solvents such as benzene or thinner, or alcohol. Do not apply water, detergent, or spray-type cleaners directly onto Console Drawer.
-
Page 31: Technical Specifications
8. Technical Specifications Model: FD-1100MT • Power Specifications Rated voltage range: 100V AC - 240V AC Frequency: 50/60Hz Rated current: 100V/0.8 A • Size Guide Rail: 30mm (W) x 610 to 855mm (infinitely adjustable) (D) x 44.0mm (H) Main part:... - Page 32 • Standard FCC Class A VCCI Class A cTUVus ICES-003...
-
Page 33: Optional Accessories (Sold Separately)
Above P/N for AC cable is US model. AC cable are available for another countries. Note 2. Contact your Fujitsu Components salespersons. Note 3. * All US drawer models include AC power cable. ** US 2-port KVM (ATL-models) includes AC adapter cable Note 4. -
Page 34: Troubleshooting
10. Troubleshooting Check the following points if you encounter problems with the Console Drawer. 10.1 No image displayed on monitor Symptom Predicted cause Solution The AC cable is not connected to Connect the AC cable properly. LED light for “Power the electric outlet, or to the switch Indicator”... -
Page 35: Monitor Cannot Be Adjusted
Sometimes no images Power cable is incorrectly Connect the power cable correctly are displayed on connected or not plugged in and make sure the plug is fully monitor fully. inserted. Letter weights are Focus or clock adjustment is Adjust clock and then focus. different across the not proper. -
Page 36: Others
Uneven thickness of The setting in FOCUS and Adjust setting in CLOCK, then adjust letters, subject to the CLOCK is not proper. the setting in FOCUS. position displayed in Displayed in lower resolution Full-screen display is made by digital monitor less than 1280 x 1024. - Page 37 memo...
- Page 39 Printed in Japan ● The contents of this manual may be modified for improvements without prior notice. ● Fujitsu bears no responsibility for infringement of patent or other rights of third parties ascribable to the use of data in this manual.
- Page 40 NC14010-L525 01 051005 This manual is made with recycled paper.
