Connecting the SRX240 Services Gateway to the AC Power Source

Figure 1 shows the SRX240 Services Gateway power supply connection.
Figure 1: SRX240 Services Gateway Power Supply Connection
To connect the device to the power supply:
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and
1.
connect the other end of the ESD strap to the ESD point on the rack.
Insert the appliance coupler end of a power cord into the appliance inlet on the
2.
power supply faceplate.
Insert the plug into an AC power source receptacle.
3.
NOTE: The device must be connected to earth ground during normal operation. The
protective earthing terminal on the rear of the chassis is provided to connect the
device to ground.
CAUTION: We recommend using a surge protector for the power connection.
NOTE: Use the cable tie holder to secure the power cord on to the power supply
point.
