Triton EDEN Bar Diverter Manual

Thermostatic bar diverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EDEN
Thermostatic
Bar Diverter
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE LABEL ON THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The mixer shower installation MUST be carried out by a suitably qualified person, in the sequence
of this instruction book.
IMPORTANT SAFETY ADVICE
The shower head and hose supplied with
this product are a safety critical part of your
shower. Failure to use genuine Triton parts may
cause injury and invalidate your guarantee.
2181383H - July 2021
86005000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDEN Bar Diverter and is the answer not in the manual?

Questions and answers

Related Manuals for Triton EDEN Bar Diverter

Summary of Contents for Triton EDEN Bar Diverter

  • Page 1 (FROM THE LABEL ON THE FRONT OR TOP OF THE BOX) this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321...

  • Page 2: Table Of Contents

    Find our step-by-step installation video for this product on our YouTube channel. Go to youtube.com/TritonShowers and search for 'how to guides'. To check the product suitability for commercial and multiple installations, please contact Triton’s specification advisory service before installation. Please see back of book for contact information.

  • Page 3: Dimensions And Main Components

    Thermostatic bar mixer shower DIMENSIONS All dimensions listed in this fitting book regarding the product and installation are approximate. MAIN COMPONENTS 1. Fixed spray arm 2. Fixed shower head 3. Rigid riser rail pipe 4. Handset 5. Handset holder 6. Hose 7.

  • Page 4: Introduction

    Thermostatic bar mixer shower INTRODUCTION Pressure Reducing Valve On sites where the running pressure is above 5 This book contains all the necessary fitting and bar, the use of a suitably sized pressure reducing operating instructions for your mixer shower. valve fitted in the cold mains supply pipework Please read them carefully and read through can provide nominally equal pressures at the...

  • Page 5: Plumbing Requirements

    Thermostatic bar mixer shower PLUMBING REQUIREMENTS Hard Water Areas DO NOT use jointing compounds on any pipe a. If it is intended to operate the shower fittings for the installation. in areas of hard water (above 200-ppm DO NOT solder fittings near the mixer shower temporary hardness), a scale inhibitor as heat can transfer along the pipework and may have to be fitted.

  • Page 6: Typical Domestic Installations

    Thermostatic bar mixer shower TYPICAL DOMESTIC INSTALLATIONS *Diagrammatic view – not to scale. *Fig.2 For illustration purposes only. Domestic Gravity Fed Systems ( fig.2) The mixer shower MUST be fed from a cold water cistern and hot water cylinder providing nominally equal pressures.
  • Page 7 Thermostatic bar mixer shower Instantaneous Gas-heated Systems, *Diagrammatic view – not to scale. *Fig.4 e.g. combination boilers (fig.4) For illustration purposes only. The mixer shower MUST be installed with a multi-point gas water heater or combination boiler of a fully modulating design i.e. to maintain relatively stable hot water temperatures.
  • Page 8 Thermostatic bar mixer shower Mains Pressurised Thermal Store Systems *Diagrammatic view – not to scale. *Fig.6 fig.6) For illustration purposes only. Packages of this type, fitted with a tempering valve (blender valve) can be used. A drop tight pressure reducing valve MUST be fitted if the supply pressures exceed 5 bar running.

  • Page 9: Installation

    Thermostatic bar mixer shower INSTALLATION *Diagrammatic view – not to scale. *Fig.7 For illustration purposes only. PREPARING THE SHOWER Check the contents to make sure all items are present. Before starting, make sure all of the openings on the valve are carefully covered to stop ingress of any debris etc.

  • Page 10: Fitting The Riser Pipe/Fixed Head

    Thermostatic bar mixer shower FITTING THE RISER PIPE/FIXED HEAD Fig.9 Mark the centre hole for the fixed head mounting bracket at a height of approximately Bracket 1040mm from the inlet datum (fig.9). mounting point IMPORTANT: All dimensions listed in this fitting book regarding the product and installation are approximate.

  • Page 11: Leak Testing

    Thermostatic bar mixer shower Install the adaptor into the top outlet of the Fig.11 mixer shower. Slide the base of the riser pipe Riser pipe into the adaptor (fig.11), making sure the sealing washer and locking collar are in place. Do not fully tighten the collar at this time.

  • Page 12: Commissioning

    Thermostatic bar mixer shower COMMISSIONING Fig.14 Start the water flow by rotating the diverter control spindle (left hand side) clockwise for the fixed shower head or anti-clockwise for the handset. Make sure that the hot and cold water supplies are fully open and at (or near to) their design temperature and pressures, and are within the Temperature requirements as stated on page 2.

  • Page 13: Temperature Adjustment Range

    Thermostatic bar mixer shower TEMPERATURE ADJUSTMENT Fig.16 RANGE The mixer shower has a temperature stop Top vertical to prevent accidental rotation to higher flat of the max temperatures. This is adjustable to provide a temp stop in maximum temperature of 35°C – 45°C. the 12 o’clock position The mixed water temperature can be adjusted...

  • Page 14: Operating The Shower (Diverter)

    Thermostatic bar mixer shower Fig.17 OPERATING THE SHOWER (Diverter) When the ON/OFF diverter control lever is at 6 o’clock, it is in the OFF position. To use the fixed head outlet turn the diverter clockwise. To decrease the flow, turn the diverter control lever back towards the OFF setting Front of mixer...

  • Page 15: Tmv2 And Flow Rates

    Thermostatic bar mixer shower TMV2 REQUIREMENTS (12 MONTHLY VERIFICATION) It is a requirement that all TMV2 approved valves shall be verified against the original set temperature results once a year. On installation and on a yearly basis please perform the following checks: 1.

  • Page 16: Maintenance

    Thermostatic bar mixer shower MAINTENANCE If these checks do not highlight the reason for the temperature variation, then internal The following maintenance procedure must components will require replacement - please be carried out for commercial and health care contact Customer Experience. premises, but is not necessarily required for domestic installations.

  • Page 17: Fault Finding

    Thermostatic bar mixer shower FAULT FINDING The following can be carried out by a competent person Problem Cause Action 1 Water too hot. 1.1 Temperature 1.1.1 Refer to the Commissioning section. control incorrectly commissioned. 1.2 Not enough cold 1.2.1 Reposition temperature control knob water flowing through shower.
  • Page 18 Thermostatic bar mixer shower FAULT FINDING Problem Cause Action 3 Water does 3.1 Water supplies cut off. 3.1.1 Check water elsewhere in house and if not flow or necessary contact local water company. shower pattern 3.2 Shower unit blocked. 3.2.1 Inspect the inlet filters. Clean if necessary. collapses when 3.3 Blockage in pipework.
  • Page 19 Thermostatic bar mixer shower...
  • Page 20 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2021...
