1

General information

1.1

Purpose of this document

This manual contains important instructions for the Webasto Go
Mobile Charger that should be followed during installation, op-
eration and maintenance of the product.
NOTE
In addition to this document, follow and comply with
local regulations and standards relating to operation,
installation and environmental protection.
1.2

Using this document

u
Read this document carefully before you install or use the
Webasto Go Mobile Charger.
u
Keep these instructions for future reference.
1.3

Intended Use

The Webasto Go Mobile Charger is designed for charging elec-
tric vehicles in accordance with IEC 62752, charge mode2. In
this charge mode, the mobile charger ensures: The voltage is
not applied before the vehicle has been connected correctly.
The maximum power is calibrated. See also: https://
www.iso.org/obp/ui/#iso:std:iec:62752:ed-1:v1:en:fig:E.1.
1.4

Use of symbols and highlighting

DANGER
This signal word denotes a hazard with a high degree
of risk which, if not avoided, may lead to death or seri-
ous injury.
WARNING
This signal word denotes a hazard with a moderate de-
gree of risk which, if not avoided, may lead to minor or
moderate injury.
CAUTION
This signal word denotes a hazard with a low degree of
risk which, if not avoided, may lead to minor or moder-
ate injury.
NOTE
This symbol denotes a special technical feature, or (if
not observed) potential damage to the product.
1.5

Warranty and liability

Webasto shall not assume liability for defects or damage that
are the result of the installation and operating instructions being
disregarded. This liability exclusion particularly applies for:
l Improper use.
l Repairs carried out by an electrician not contracted by
Webasto.
l Use of non-original spare parts.
l Unauthorised conversion of the unit without permission
from Webasto.
l Installation and commissioning by unqualified staff (not an
electrician).
l Improper disposal after decommissioning.
NOTE
In case of any claims, defects or damage to your pro-
ject, you must contact your direct contractual partner,
installation partner or dealer.
WARNING
Installation and connection of the charging station must
only be carried out by a qualified electrician.
5911743-A-01 Webasto Go
The symbol of a bin with a line through it means that
the instructions in the chapter on Disposal must be fol-
lowed.
The Webasto Go Mobile Charger should not be oper-
ated at altitudes of more than 13,123 ft. (4000 m)
above sea level.
2 Important safety
information
Read and comply with warnings in this User Guide.
2.1 General information
The Webasto Go Mobile Charger is an easy-to-use, compact
portable power supply for electric vehicle. The charger supplies
and manages AC power to your electric vehicle and is compat-
ible with a variety of battery electric vehicles and plug-in hy-
brids.
The charger operates from a 120 – 240 VAC (Single Phase) 50 –
60 Hz power source.
Key features:
l Compact portable design
l Overheating protection
l Quick-read status indicators
l Multiple adapters available for versatile usage in a variety of
locations
l Overvoltage protection
2.2

General safety information

WARNING
This product must be grounded. If it should malfunction
or break down, grounding provides a path of least res-
istance for electric current to reduce the risk of electric
shock. This product comes with two adapters, each ad-
apter has an grounding adapter and a grounding plug.
The adapter must be inserted into an appropriate wall
socket that is properly installed and grounded in ac-
cordance with all applicable local and national stand-
ards and regulations.
WARNING
Risk of electric shock
Improper connection of the electrical wall socket
grounding conductor might result in a risk of electric
shock. Check with a qualified electrician if you are un-
certain whether or not the electrical wall socket is prop-
erly grounded. Do not modify the plug provided with
the product if it does not fit in the wall socket. Have a
proper wall socket installed by a qualified electrician.
WARNING
Electrical wall sockets for use with your charger must be
installed by a licensed, qualified electrician. To avoid
serious injury or death, installation must comply with all
applicable local and national standards and regulations.
WARNING
Do NOT DROP the control box or coupler.
Do NOT use if stored outside temperature range spe-
cified.
General information | 1
3 / 12
