Programmable Switch Functions
A special button on the outside of the housing can be configured to
provide several different functions, or to be inoperative by selecting
(none).
The ProgSw button on the keypad opens a setup screen to select the
programmable switch function. Enter this setup screen and then use
the UP/DOWN arrows to select the desired function and press the
MENU/SEL button to return to the Setup Window.
The ProgSw menu provides a scrollable list of the available functions.
Use the UP/DOWN arrows to highlight the desired function and press
BACK or MENU/SEL to select it and return to the main menu.
ProgSw ProgSw
Power Power
ProgSw
Cough
14
Programmable Switch
PROG/SW
Button
Power turns the power on and off.Hold the button
on the housing in until the countdown sequence from
3 to 1 is completed. The power will then be turned
off.
NOTE: When the button on the housing is set
to Power, it will turn on the transmitter in the
operating mode with the RF output on.
Cough is a momentary mute switch. Audio is muted
while the button on the housing is held in.
• Power
• Cough
• Mute
• (none)
• TalkBk
• PTT
Press the PROG/SW
button or select ProgSw
in the Setup menu.
