Sinope TH1500NP Installation Manual

TH1500NP
Installation Guide
Double-Pole Thermostat
for Electric Heating
INSTALL YOUR THERMOSTAT
Make sure that the
1
breakers for your heating
system are off at the main
electrical panel.
5 Replace the cover
and lock.
2
Unlock and lift the
thermostat cover.
6 Power up the
Make sure to firmly tighten the wire connectors for a
thermostat.
secure connection. A loose connection can be a fire
hazard.
To install wire connectors, you must:
1
2
Set
3
YOUR TH1500NP THERMOSTAT
Set
Warnings
The installation of this thermostat must be
performed by a certified electrician and comply
with the national and local electrical codes and
regulations.
Use the provided connectors
3
to connect the load/line
wires located on the back
of the thermostat.
Insert the two wires into the wire nut so that their
copper ends are parallel.
Turn the wire connector clockwise until there is strong tension.
Pull on the threads to make sure they are secure, leaving no
gaps between them. * If the threads seem to come loose,
repeat the process.
* Improperly installed electrical wires could burn the wire connectors.
Ambient temperature
Setpoint temperature
Heating indicator
Use the screws to
4
secure the
thermostat to the
electrical box.
3/4"
