SAVE THESE INSTRUCTIONS
• Which kind of salt to use:
Use only Sodium Chloride Salts
Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use water conditioning salt pellets (the
compressed forms of evaporated salt). However, it will take a longer time for them to dissolve. Do not use iodized or yellow (yellow
prussiate of soda) colored salt. Salt is added to the pool water and the electrolytic cell uses this salt to create the sanitizer. The
purer the salt the better the performance of the electrolytic cell.
• Optimum Salt Levels
The ideal salt level in the pool water is between 2500‐3500 ppm (parts per million).
The optimal level is 3000 ppm.
A too low salt level will reduce the efficiency of the saltwater system and result in low sanitizer production. A high salt level may
generate a salty taste to the pool water (this may occur at a salt level above 3500‐4000ppm). Too high of a salt level may damage the
power supply and cause corrosion to pool metal fixtures and accessories. The Salt Table page of this manual shows the correct dosage
of salt needed. The salt in the pool is constantly recycled. Salt loss occurs only when pool water is physically removed from the pool.
Salt is not lost due to evaporation.
• Adding Salt
1.Switch the filter pump on to start water circulation
2.Keep the saltwater system turned off.
3.Determine the amount of salt to be added (see "Salt Table").
4.Evenly spread the proper amount of salt around the inside perimeter of the pool.
5.Avoid clogging the filter by not adding salt through the skimmer.
6.Brush the pool bottom to speed up the dissolving process. Do not allow salt to pile up on the bottom of the pool. Run the filter pump
24 consecutive hours to thoroughly dissolve the salt.
7.After 24 hours and if all the salt is dissolved, turn on the Saltwater System, press
flashing (see "System Operation" section steps 2 to 4) and set the saltwater system to desired
operating time (see "Operating Time Table").
• Removing Salt
If too much salt has been added, the unit will beep and display "code 92" (see "Alarm Codes"). You will need to lower the salt
concentration. The only way to do so, is to partially drain the pool and refill it with fresh water. Drain and refill approximately 20% of the
pool's water until the "Code 92" disappears.
• Pool Volume Calculation
Types of Pool
Rectangular Length x Width x Average Depth x 7.5
Circular Length x Width x Average Depth x 5.9
Oval Length x Width x Average Depth x 6.0
SALT & POOL WATER VOLUMES
Gallons (pool size in feet)
button until you hear a "beep", code "00"
Cubic Meters (pool size in meters)
1 cubic meter = 1000L
Length x Width x Average Depth
Length x Width x Average Depth x 0.79
Length x Width x Average Depth x 0.80
