IADS-PROG IADS
Connection Hub User
Guide
Content
Copyright © 2019 UTC Fire & Security Americas Corporation, Inc. All rights
reserved.
Description
The IADS-PROG IADS connection hub is designed for the following functions:
•
It allows to connect computers (notebooks, desktop PCs, etc.) to ATS control
panels, creating a bridge between a USB port of the computer and an RS232
connection of the control panel. See "USB to serial converter mode" on page
4 for more details.
•
It also allows address programming for addressable detectors or other
components (for example, magnetic contact type MK 46 AD), which do not
provide a physical way of address change. The programming mode allows
connecting a detector or component via two-wire cable to a USB port of a
computer, which runs an application to monitor the device and to change the
P/N 1070544 (EN) • REV B • ISS 11MAR19
1
Advertisement
Table of Contents
Related Manuals for Interlogix IADS-PROG
Summary of Contents for Interlogix IADS-PROG
- Page 1 Copyright © 2019 UTC Fire & Security Americas Corporation, Inc. All rights reserved. Description The IADS-PROG IADS connection hub is designed for the following functions: • It allows to connect computers (notebooks, desktop PCs, etc.) to ATS control panels, creating a bridge between a USB port of the computer and an RS232 connection of the control panel.
- Page 2 corresponding address in an IADS network. See “IADS device programming mode” on page 4 for more details. Packaging The packaging includes the following components: • 1 x User Guide (this document) • 1 x USB-A to USB-B connection cable • 1 x IADS connection hub •...
- Page 3 Setup and connections The IADS connection hub is shown in Figure 1 below. Figure 1: IADS connection hub layout Yellow LED to serial converter USB connector button RS232 connector Green LED IADS Programming mode 2-way onnector • The RS232 plug can be connected with an RS232 cable (male — male, 9-pin connectors) to the ATS control panel.
- Page 4 Avoid detaching the IADS connection hub either from a control panel, a programmable device, or from a PC, when the actual programming or data exchange function is in progress — it can affect correct and successful operation. USB to serial converter mode This mode allows to connect ATS control panels, that currently have a 9-pin RS232 connector, transparently to a computer (usually a notebook), which are mostly equipped only with USB ports.
- Page 5 Figure 3: IADS device programming mode IADS connetion two-core cable Point ID contact Connect the IADS connection hub as shown in Figure 3 above. The IADS connection hub should be connected via the USB cable to the computer. Connect a programmable device via two-wire cable to the IADS connection hub, and press Mode button to set the addressing mode, until the green LED is on.
- Page 6 If a device found which is recognized by the application, the device name will be displayed in the field “Device Name” as well as the corresponding attributes and the current address. The state will be “Operation successful”. If no device or an unknown device is connected, the field “Device Name” will show “No device”...
- Page 7 Directive 2014/30/EU and/or 2014/35/EU. For more information see www.utcfireandsecurity.com or www.interlogix.com. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
- Page 8 P/N 1070544 (EN) • REV B • ISS 11MAR19...
