Summary of Contents for Carestream DENTAL CS 3700
- Page 1 CS 3700 User & Installation Guide...
- Page 2 © Carestream Dental LLC, 2022. The information in this document is subject to change. Neither Carestream Dental LLC nor any of its subsidiaries shall be liable for errors contained herein or for incidental damages in conjunction with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Guide Chapter 2 CS 3700 Overview ..... . . 3 CS 3700 Overview CS 3700 Holder Overview....5 CS 3700 Shade Calibration Unit Overview . -
Page 5: Conventions In This Guide
Did you find the information in this document helpful? Were you looking for information that was not in this document? Take our short survey and help us make this document better. Click http://guest.cvent.com/d/sdqtll/3B to open the questionnaire. CS 3700 User and Installation Guide (TA1306)_Ed04... - Page 6 Chapter 1 Conventions in This Guide...
-
Page 7: Cs 3700 Overview
CS 3700 Overview The CS 3700 is designed to acquire 3D still images in the following modes: Lower jaw Upper jaw Buccal bite registration CS 3700 Overview Figure 1 CS 3700 Components Overview 1 Reusable tip There are three types of tips: Normal, facing downward; Side, facing left;... - Page 8 Connects the scanner to the power adapter. 8 Power adapter One end of the adapter is inserted in the small jack on the power box, and the other end is inserted in the power outlet. Chapter 2 CS 3700 Overview...
-
Page 9: Cs 3700 Holder Overview
The holder can be used as a desktop or a wall mount holder. Place the scanner in the holder when you are not using it. Figure 2 Scanner in Desktop Holder Figure 3 Scanner in Wall Mount Holder CS 3700 User and Installation Guide (TA1306)_Ed04... -
Page 10: Cs 3700 Shade Calibration Unit Overview
To use the scanner again, put on the tip. Note: When the scanner is idle for more than an hour, it powers off. CS 3700 Shade Calibration Unit Overview After 50 hours of scanning (approximately 13 days), use the shade calibration unit to recalibrate the scanner. -
Page 11: Cs 3700 Wrist Strap Overview
See the CS ScanFlow User Guide for more information. CS 3700 Wrist Strap Overview Mount the wrist strap to the eyelet on the end of the scanner. Figure 5 CS 3700 with Wrist Strap Follow these recommendations: Ensure that the wrist strap and the wrist strap eyelet are in good condition before placing the strap on your wrist. -
Page 12: Cs 3700 Usb Cable Storage
Figure 6 Using the CS 3700 with the Wrist Strap It is recommended that you use the wrist strap when scanning to prevent accidentally dropping the scanner. CS 3700 USB Cable Storage To avoid damaging the USB cable of the scanner, you should loosely coil the cable and avoid creating any sharp kinks, especially in the area where the cable connects to the scanner. -
Page 13: Setting Up The Scanner
Click Exit. Firmly slide one of the tips onto the end of the scanner. Ensure that the arrow on the end of the tip is aligned with the arrow on the decorative ring. CS 3700 User and Installation Guide (TA1306)_Ed04... - Page 14 Insert the scanner connector (A) into the large jack on the end of the power box (B), and insert the DC power supply (C) into the small jack on the power box. Connect the USB cable (D) to the computer, and insert the power adapter (E) into an outlet. Press the power button one second to power on the scanner.
-
Page 15: Using The Desktop Holder
Important: Adhesive tape can lose its adherence capability due to environmental and other factors. Check the adherence regularly to ensure that it is secure. Important: Carestream Dental LLC is not responsible for accidents or damage involving the scanner falling due to loosening of the adhesive tape. -
Page 16: Installing The Wall Mount Holder
Installing the Wall Mount Holder To use the holder as a wall mount holder, follow these steps: Select an area that you can access easily. Insert screws through the appropriate holes in the holder to affix it to a solid surface. Important: If the holder is not properly installed, there is a risk that the holder can fall off the wall, resulting in damage to the scanner. -
Page 17: Preparing The Scanner
Do not touch the heating element at the base of the scanner. Important: Use the posterior tip in hard-to-reach areas and for quadrant scanning only. Use the normal tip or the side-facing tip when scanning a full arch. CS 3700 User and Installation Guide (TA1306)_Ed04... - Page 18 Press the power button for one second to power on the scanner. Let the scanner warm up for approximately three minutes to enable the antifog feature on the tip. On the CS ScanFlow interface, select the Upper Jaw acquisition mode. On the scanner, press the mode button for one second to select the acquisition mode.
-
Page 19: Cleaning, Disinfecting, And Sterilizing
The removable scanner tips can be autoclaved for up to 20 cycles. After 20 cycles, discard the tip. If you limit the holding time at 134°C to not more than 4 minutes, you can autoclave the tip up to 60 cycles. See the CS 3700 Safety, Regulatory, and Technical Specifications User Guide for more information. - Page 20 Chapter 4 Maintenance...
-
Page 21: Cs 3700 Troubleshooting Instructions
If the fogging does not disappear completely after the scanner powers off (over 1 hour), contact your local service provider for assistance. CS 3700 User and Installation Guide (TA1306)_Ed04... - Page 22 Chapter 5 Troubleshooting...
-
Page 23: Manufacturer's Address
List of Importers for European Union According to the MDR 2017/745 Carestream Dental France SAS 4 Rue F. Pelloutier, Croissy-Beaubourg 77435 Marne-la-Vallée Cedex 2, France Carestream Dental Germany GmbH Hedelfinger Str. 60 70327 Stuttgart, Germany CS 3700 User and Installation Guide (TA1306)_Ed04... - Page 24 Carestream Dental Spain, S.L.U. Paseo de la Castellana, 79 Madrid 28046, España Carestream Dental Italy S.r.l. Via Mario Idiojmi 3/3 Assago 20090 (MI), Italia Chapter 6 Contact Information...
- Page 25 For more information, visit: carestreamdental.com To give documentation feedback, visit: carestreamdental.com/documentationfeedback © 2022 Carestream Dental LLC. Ed04 TA1306 2022-02...
