Symbols
•)))
mV, V
Ω, kΩ, MΩ
uA, mA, A
pF, nF, uF
Hz kHz
%
O O
F, C
AUTO
BAT
HOLD
REL
Operating Instructions
AC or DC Voltage Measurements
1. Insert the black test lead banana plug into the negative COM jack
and the red test lead banana plug into the positive V jack.
2. Turn the rotary switch to the VAC or VDC position.
3. Touch the test probes to the circuit under test and read the voltage
on the display.
AC (alternating current or voltage)
DC (direct current or voltage)
Continuity
Diode test
millivolt, volt (voltage)
ohm, kilohm, megohm (resistance)
microamp, milliamp, Amp (current)
picofarad, nanofarad, microfarad (capacitance)
hertz, kilohertz (frequency)
% duty cycle
Degrees fahrenheit, centigrade (temperature)
Autorange
Low battery
Display hold
Relative
