jWIN JX-CD8500 Owner's Manual

Stereo hi-fi system with 4 cd changer / mp3 and am/fm pll synthesized tuner
Hide thumbs Also See for JX-CD8500:
Table of Contents

Advertisement

Quick Links

JX-CD8500 STEREO HI-FI SYSTEM
with 4 CD CHANGER / MP3
and AM/FM PLL SYNTHESIZED TUNER
OWNER'S MANUAL
JXCD8500V10M11EN05022005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JX-CD8500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for jWIN JX-CD8500

Summary of Contents for jWIN JX-CD8500

  • Page 1 JX-CD8500 STEREO HI-FI SYSTEM with 4 CD CHANGER / MP3 and AM/FM PLL SYNTHESIZED TUNER OWNER'S MANUAL JXCD8500V10M11EN05022005...
  • Page 2 WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PRESENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 3: Installation (Wall Mounting)

    INSTALLATION MAIN UNIT ASSEMBLY AND DISASSEMBLY STEP 1 STEP 2 SPEAKER ASSEMBLY AND DISASSEMBLY STEP 1 STEP 2 INSTALLATION (Wall Mounting) Secure the center unit and speakers on the wall (as show below) using 8 dowels and 8 screws (supplied). STEP 3 STEP 3...
  • Page 4 CONTROLS Front view POWER Button Interrupts the CD playback / clearing the CD Used to turn the system on and off programme, provides stereo-mono switching for RIGHT CD DOOR DISPLAY FM stations VOLUME UP/DOWN Button REPEAT/PRESET Button Repeat function for CD mode / retrieve preset Used to select the desired volume radio stations CD SELECTION 1-4 Button...

  • Page 5: Remote Control

    Antenna connection AC power connection You can achieve acceptable reception if you use Connect the power cable (included in the the supplied FM “pigtail” antenna. If so, the antenna accessories) first to the power socket (27) at the should be elongated and not coiled or bunched up. unit and then insert the power plug into the wall If it hangs freely, it can be quite effective.
  • Page 6 AMPLIFIER AND RADIO FACILITY Switching the unit ON AM/FM radio operation Switch the unit on by pressing the "POWER" button Press the "POWER" button (1)/(32) to turn on the (1)/(32). Switch to the Tuner operating mode by system. pressing the button "TUNER / BAND" (7)/(53). Operating mode selection The different operating modes can be directly selected using the buttons “PLAY / PAUSE...

  • Page 7: Digital Clock And Timer

    DIGITAL CLOCK AND TIMER Setting the digital clock 3. To set the minutes, press the MEM./CLK ADJ. again and use When you first plug in the unit, the display shows: Confirm by pressing MEM./CLK ADJ. 4. Press DISPLAY MODE to proceed to setting the switch-off time.

  • Page 8: Playing Mp3 Discs

    The selected number appears on the display. If the Random play CD player is in stop mode, play starts automatically Press RANDOM on the remote control before or when a track is selected using the numerical during CD play. The tracks in the CD will be played buttons.

  • Page 9: Care And Maintenance

    4. Press the “ TUNING + or TUNING -” button (18) or (20) to select desired track. 5. Press the “PLAY/PAUSE” button to play MP3. Press the “REPEAT” button again to have the entire MP3 disc played continuously. Pause / stop To briefly pause playback, press the “...

  • Page 10: Specifications

    SPECIFICATIONS GENERAL Power requirement Power consumption Dimension Satellite Spkrs RECEIVER SECTION Receiving bands Tuning range CD PLAYER SECTION Playback system Frequency response AUDIO SECTION Power output Speaker impedance Headphone impedance ACCESSORIES Power AC cord Instruction Manual Remote Control handset 120V ~ 60Hz Battery size “CR2032”...
