Model No. HRCCEL69011
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manu-
al for future reference.
USER'S MANUAL
Visit our website at
www.healthrider.com
Advertisement
Table of Contents
Related Manuals for ICON Health & Fitness HealthRider HRCCEL69011
Summary of Contents for ICON Health & Fitness HealthRider HRCCEL69011
- Page 1 Model No. HRCCEL69011 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 1-888-936-4266 Mon.–Fri. 8h00 until 18h30 EST (excluding holidays).
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical crosstrainer. 1. Read all instructions in this manual before 8. Wear appropriate exercise clothing when using the elliptical crosstrainer. using the elliptical crosstrainer. Always wear athletic shoes for foot protection. -
Page 4: Before You Begin
BEFORE YOU BEGIN Congratulations for selecting the new HealthRider ® questions, call our Customer Service Department toll- 860. The HealthRider ® 860 is an incredibly smooth free at 1-888-936-4266, Monday through Friday, 8h00 exerciser that moves your feet in a natural elliptical until 18h30 Eastern Time (excluding holidays). -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the elliptical crosstrainer in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included allen wrenches, assembly requires a phillips screwdriver , an adjustable wrench , and a rubber mallet... - Page 6 1. Identify the Front Stabilizer (3), which has Wheels (32) attached to it. While another person lifts the front of the Frame (1), attach the Front Stabilizer to the Frame with two M10 x 112mm Carriage Bolts (34) and two M10 Nylon Locknuts (29).
- Page 7 5. The Console (5) requires four “D” batteries (not includ- ed); alkaline batteries are recommended. Refer to the inset drawing. Press the tab on the battery cover, and lift off the battery cover. Insert four batteries into the battery compartment. Make sure that the batteries are oriented as shown by the diagram inside the battery compartment.
- Page 8 8. Identify the Left Pedal (13). Attach the Left Pedal to the left Flex Bar (14) with an Adjustment Bolt (20), an M10 Washer (38), and an Adjustment Knob (15) as shown. Note: The Left Pedal can be attached in any of five positions (see HOW TO ADJUST THE PEDALS on page 9).
-
Page 9: How To Use The Elliptical Crosstrainer
HOW TO USE THE ELLIPTICAL CROSSTRAINER HOW TO ADJUST THE PEDALS To dismount the elliptical crosstrainer, wait until the pedals come to a complete stop. Note: The elliptical The motion of the crosstrainer does not have a free wheel; the ped- pedals is deter- als will continue to move until the flywheel stops. - Page 10 FEATURES OF THE CONSOLE sonal trainer right in your home. Using a stereo audio cable (available at electronics stores), you can connect The advanced console offers a selection of features the elliptical crosstrainer to your home stereo, portable designed to make your workouts more enjoyable and stereo, or computer and play special iFIT.com CD pro- effective.
- Page 11 CONSOLE DESCRIPTION currently shown. Note: When the distance is shown, the word Miles or the letters Kms will Refer to the drawing on page 10. Note: If there is a appear; when your speed is shown, the letters MPH thin sheet of clear plastic on the face of the con- or Km/H will appear.
- Page 12 changes, the console will show the resistance HOW TO USE THE MANUAL MODE level for six seconds. In addition, when a Smart program or a Heart Rate program is selected, the display will show the time remaining in the pro- Turn on the console.
- Page 13 The pace set- HOW TO USE A SMART PROGRAM tings for the pro- gram will be shown by the Turn on the console. right bar graph in Increase Arrow the display. (The Refer to step 1 on page 12. left bar graph will show your actual Select one of the eight Smart programs.
- Page 14 Hold the handgrip pulse sensor . HOW TO USE A HEART RATE PROGRAM When using a Heart Rate program, you must use the handgrip pulse sensor (refer to step 5 on Each Heart Rate program helps you to keep your page 12) or the optional chest pulse sensor (refer heart rate near a certain percentage of your maximum to page 20).
- Page 15 right bar graph changes, increase or decrease HOW TO CONNECT YOUR CD PLAYER, VCR, your pace so that the same number of bars OR COMPUTER appear in both bar graphs. If your pace is slower than the current pace setting, the increase arrow will also appear in the display;...
- Page 16 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an RCA-type AUDIO OUT Note: If your stereo has an unused LINE OUT jack, jack, see instruction A below. If your stereo has a see instruction A below.
- Page 17 HOW TO CONNECT YOUR COMPUTER HOW TO CONNECT YOUR VCR Note: If your computer has a 1/8” LINE OUT jack, Note: If your VCR has an unused AUDIO OUT jack, see instruction A. If your computer has only a see instruction A below. If the AUDIO OUT jack is PHONES jack, see instruction B.
- Page 18 Press the play button on your CD player or HOW TO USE IFIT.COM CD AND VIDEO VCR. PROGRAMS A moment after the play button is pressed, your personal trainer will begin guiding you through To use iFIT.com CDs or videocassettes, the elliptical your workout.
- Page 19 Start your Web browser, if necessary, and go HOW TO USE PROGRAMS DIRECTLY FROM to our Web site at www.iFIT.com. OUR WEB SITE Follow the desired links on our Web site to select a program. Our Web site at www.iFIT.com allows you to play iFIT.com audio and video programs directly from the Read and follow the on-line instructions for using internet.
-
Page 20: Maintenance And Troubleshooting
THE OPTIONAL CHEST PULSE SENSOR The optional chest pulse sensor provides hands-free operation and continuously monitors your heart rate during your workouts. To purchase the optional chest pulse sensor, call toll-free 1-888-936-4266. MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical crosstrainer HANDGRIP PULSE SENSOR TROUBLESHOOTING regularly. -
Page 21: Conditioning Guidelines
CONDITIONING GUIDELINES During the first few minutes of exercise, your body WARNING: uses easily accessible carbohydrate calories for ener- gy. Only after the first few minutes of exercise does Before beginning this or any exercise pro- your body begin to use stored fat calories for energy. gram, consult your physician. -
Page 22: Part List
PART LIST—Model No. HRCCEL69011 R0802A Key No. Qty. Description Key No. Qty. Description Frame M10 x 25mm Flat Screw Upright Idler Bearing Front Stabilizer Idler Wheel Rear Stabilizer M10.3 Black Washer Console “C” Magnet Left Side Shield Motor Right Side Shield Belt Cover Disc M8 x 33mm Button Screw... -
Page 23: Exploded Drawing
EXPLODED DRAWING—Model No. HRCCEL69011 R0802A 70 71 63 64 57 45 45 46... -
Page 24: How To Order Replacement Parts
HOW TO ORDER REPLACEMENT PARTS To order replacement parts, call toll-free 1-888-936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER of the product (HRCCEL69011) •...
