- Page 1 ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION OAK MADRA BED - WITHOUT SLATS 51201 OAK MADRA BED - WITHOUT SLATS 180/200/71 51202 OAK MADRA BED - WITHOUT SLATS 160/200/71...
- Page 2 OAK MADRA BED - WITHOUT SLATS ASSEMBLY INSTRUCTION FOR BED INSTALLATION HARDWARE ENCLOSED TOOL (10X) (4X) (6X) (6X) L KEY JCBC SCREW JCBC SCREW JCBC SCREW L BRACKET 6 X 45 mm (Included in package) 6 X 20 mm 6 X 6 mm (1X) COUNTERSUNK (12X)
- Page 3 OAK MADRA BED - WITHOUT SLATS ASSEMBLY INSTRUCTION FOR BED INSTALLATION INSTALLING SIDE RAILS TO HEADBOARD - USE DOWEL Ø12x40 mm (8X) - USE JCBC SCREW M6x45mm (4X) - SCREW LOCATION ON THE BACK SIDE OF BEDHEAD - DO NOT FULLY TIGHTEN INSTALLING FOOTBOARD TO SIDERAILS - USE DOWEL Ø12x40 mm (4X)
- Page 4 OAK MADRA BED - WITHOUT SLATS ASSEMBLY INSTRUCTION FOR BED INSTALLATION INSTALLING MIDDLE LEG TO MIDDLE SUPPORT - USE COUNTERSUNK SCREW M6x50mm (1X) - TIGHTEN FULLY INSTALLING MIDDLE SUPPORT TO ADJUST HEIGHT - USE JCBC SCREW M6x6mm (2X) FOR STEP 2 - USE JCBC SCREW M6x20mm (4X) FOR STEP 3 - DO NOT FULLY TIGHTEN...
- Page 5 OAK MADRA BED - WITHOUT SLATS ASSEMBLY INSTRUCTION FOR BED INSTALLATION INSTALLING L BRACKET - USE JCBC SCREW M6x6mm (4X) - DO NOT FULLY TIGHTEN TIGHTEN FULLY ALL SCREWS...
