DNAfx GiT Mobile
multi effects unit
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Harley Benton DNAfx GiT Mobile and is the answer not in the manual?

Questions and answers

Related Manuals for thomann Harley Benton DNAfx GiT Mobile

Summary of Contents for thomann Harley Benton DNAfx GiT Mobile

  • Page 1 DNAfx GiT Mobile multi effects unit user manual...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 21.03.2022, ID: 532855...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 9 Safety instructions..........................11 Features............................... 13 Starting up..............................14 4.1 Dealing with lithium batteries..................... 14 4.2 Charging the unit..........................16 Connections and operating elements...................
  • Page 4 Table of contents 6.5 Bluetooth® audio..........................22 Amps and effects list..........................23 Technical specifications........................28 Plug and pin assignments........................30 Protecting the environment......................32 multi effects unit...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. DNAfx GiT Mobile...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...
  • Page 8 General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Cross-references References to other locations in this manual are identified by an arrow and the specified page number.

  • Page 9: Symbols And Signal Words

    General information 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
  • Page 10 General information Warning signs Type of danger Warning – danger zone. multi effects unit...

  • Page 11: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for sound processing of signals from musical instruments with electromagnetic pickups. Any other use or use under other operating conditions is con‐ sidered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 12 Safety instructions WARNING! Incorrect handling of lithium batteries can result in injury In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Follow the advice on the correct handling of lithium batteries in the present section. NOTICE! Operating conditions This device has been designed for indoor use only.

  • Page 13: Features

    Features Features Special features of the device: Direct connection to the electric guitar with a 1/4" rotatable jack plug 14 amp modelings 14 different high-quality digital effects Five Tone/EQ Settings USB-C port for audio recordings and charging the unit Headphones output, designed as 1/4" jack socket Bluetooth®...

  • Page 14: Starting Up

    Starting up Starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 15 Starting up Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are hermetically sealed. Never attempt to open a lithium battery. If the battery housing is damaged small amounts of the electrolyte may leak out. If this should happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte using absorbent paper towels.

  • Page 16: Charging The Unit

    Starting up 4.2 Charging the unit If the status LED of the main switch flashes blue when the unit is switched on, only a maximum of 30 minutes of battery life remains. Switch off the unit and connect the unit via the USB-C cable to the AC outlet. During charging, the status LED of the main switch lights up red.

  • Page 17: Connections And Operating Elements

    Connections and operating elements Connections and operating elements ö & DNAfx GiT Mobile DNAfx GiT Mobile...
  • Page 18 Connections and operating elements 1 [AMP] Button to call up the amp modeling models 2 [TONE] Button to call up the timbre of the amp modeling models 3 [EFX] Button to call up the digital effects of the amp modeling models Button to toggle between the menu items and to decrease a value Button to toggle between the menu items and to increase a value 6 1/4"...

  • Page 19: Operating

    Operating Operating Turn the volume control counter-clockwise to set the volume to minimum. Switch on the unit and adjust the volume as required. 6.1 Selecting the amp modeling model Press [AMP] to call up the amp modeling models. Press to toggle between the 14 different the amp modeling models. ð...

  • Page 20: Selecting Timbre

    Operating 6.2 Selecting timbre Press [TONE] to enable the timbre of the selected amp modeling model. Press to toggle between the five different timbres. ð The LED [TONE] lights up in the corresponding colour (see Ä ‘TONE’ on page 25). Press and hold [AMP] to confirm the selection.

  • Page 21: Selecting Digital Effects

    Operating 6.3 Selecting digital effects Press [EFX] to enable the effect of the selected amp modeling model. Press to toggle between the 14 different effects. ð The LED [EFX] lights up in the corresponding colour (see Ä ‘EFX’ on page 26). Press again [EFX] to confirm the selected effect.

  • Page 22: Usb Audio

    Operating 6.4 USB audio The unit can be used as USB-C audio interface with support for DAWs in Windows® and MAC. Windows® users have to install ASIO drivers to achieve low-latency recording and monitoring. 6.5 Bluetooth® audio Set the main switch to to enable the Bluetooth® function for the audio playback. Open the Bluetooth®...

  • Page 23: Amps And Effects List

    Amps and effects list Amps and effects list Number LED colour Name Template/description US DOUBLE Clean Fender® 65 Twin Reverb US DELUXE Clean Fender® 65 Deluxe Reverb ACOUSTIC SIM Acoustic guitar simulation SONIC DRIVE Fender® Super Sonic US 59 BASS Fender®...
  • Page 24 Amps and effects list Number LED colour Name Template/description CALI V Mesa Boogie® Mark V 30 Oranges Orange® AD 30 SOLDIER 100 DS Soldano® SLO 100 5153 Crunch EVH® 5150 III All trademarks and product names are the property of their respective owners and are used as reference for the effect types in this user manual.
  • Page 25 Amps and effects list TONE Number LED colour Name Darker Dark Flat Bright Brighter DNAfx GiT Mobile...
  • Page 26 Amps and effects list Number LED colour Name Room Reverb Hall Reverb Church Reverb Plate Reverb Spring Reverb Mod Reverb Slapback Delay Tape Dly+Hall Reverse Dly+ModReverb PingPong Dly+Church Chorus+Hall Phaser+Church multi effects unit...
  • Page 27 Amps and effects list Number LED colour Name Flanger+Plate Tremolo+ModReverb DNAfx GiT Mobile...

  • Page 28: Technical Specifications

    Technical specifications Technical specifications Input connections Power supply/USB audio USB-C socket Output connections Instrument 1/4" jack socket Headphones 3.5 mm phone socket Power supply External power adapter, 100 - 240 V 50/60 Hz Operating voltage 3.7 V / 130 mA Battery / rechargeable battery Battery type Lithium-ion...
  • Page 29 Technical specifications Standard Version 5.0 Dimensions (W × H × D) 42 mm × 31 mm × 83 mm Weight 59 g Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) Further information Effect type Headphone amplifier Number of control channels Volume control per channel Number of inputs...

  • Page 30: Plug And Pin Assignments

    Plug and pin assignments Plug and pin assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
  • Page 31 Plug and pin assignments Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding...

  • Page 32: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 33 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose of this device through an approved waste disposal firm or through your local waste facility.
  • Page 34 Notes multi effects unit...
  • Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
