Table of contents Table of contents General information..........................6 1.1 Symbols and signal words....................... 6 Safety instructions............................. 8 Features............................... 11 Installation and starting up........................ 13 4.1 General Information........................13 4.2 Receiver............................... 14 Connections and controls........................16 5.1 Receiver............................... 16 5.2 Transmitter............................19 5.3 Battery charging station........................
Page 4
Table of contents Plug and connection assignment....................34 Troubleshooting............................36 Protecting the environment......................38 GigA Pro Pedal Set Wireless System...
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
Page 7
General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
Safety instructions Safety instructions Intended use This device is intended to be used for the wireless transmission of audio signals from micro‐ phones or instruments to amplifiers or active speakers. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage.
Page 9
Safety instructions WARNING! Incorrect handling of lithium batteries can result in injury! In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Handle lithium bat‐ teries in a correct and professional manner. Store lithium batteries in a cool and dry place in their original packaging. Keep lithium batteries away from sources of heat.
Page 10
Safety instructions NOTICE! Possible damage to lithium-ion batteries through incorrect storage! Deep discharge can permanently damage lithium-ion batteries or cause them to lose some of their capacity. Charge the lithium-ion batteries before longer breaks in use and before storage. Ensure that the device is switched off for storage. Store the device at room temperature or cooler in an environment as dry as possible.
Features Features The Wireless System GigA Pro Pedal Set consists of the following components: GigA Pro pedal receiver: – Built-in antenna for optimum reception quality – Compatible with all transmitters of the GigA series – Automatic frequency scan, up to eight frequencies in parallel –...
Page 12
Features – Three-digit display for battery capacity – Flexible stub antenna – Screwed adapter from 3.5 mm to 1/4" jack socket Battery charging station GigA Pro MP24 Extension instrument cable, metal clip for guitar strap The system operates at 2.400 GHz … 2.4835 GHz and is worldwide free of charge and registra‐ tion.
Installation and starting up 4.2 Receiver Connecting the power supply NOTICE! Damage to the external power supply due to high voltages! The device is powered by an external power supply. The external power supply can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur.
Page 15
Installation and starting up Connecting audio and starting Connect one of the audio outputs of the receiver to your mixer or your amplifier. The following figure shows an example of how the device can be integrated into your signal chain. Mixer PROG.01 Out C...
Connections and controls Connections and controls 5.1 Receiver Front panel GigA Pro PR ö 9-12V DC IN MICRO SD OUT C POWER & ' & GigA Pro Pedal Set Wireless System...
Page 17
Connections and controls 1 [ACT] | Starts the synchronisation of the settings with the transmitter. 2 Display 3 [SELECT] | Press the jog wheel to open the menu and turn it to select a menu item. Press the jog wheel again to call up the menu item.
Page 18
Connections and controls 13 [OUT B] | 6.35-mm jack socket as unbalanced audio signal output B for direct connection to a guitar amplifier or bass amplifier 14 [OUT A] | 6.35-mm jack socket as unbalanced audio signal output A for direct connection to a guitar amplifier or bass amplifier Display 1 Shows the outputs to which the audio signal is passed.
Connections and controls 5.2 Transmitter 1 [ACT] | Infrared sensor ö 2 Battery status indicator. If the last remaining segment lights up red, at most 25% of the battery capacity remain. 3 [ON] | Main switch. Press the switch for several seconds to switch the device on or off.
Connections and controls 5.3 Battery charging station ö 1 Charging slot 2 Power indicator. Lights up when the device is connected to the power supply. GigA Pro Pedal Set Wireless System...
Page 21
Connections and controls 3 Connection for the supplied power supply 4 Charging indication. The red LED lights up during charging, while the green LED lights up when the device is charged. GigA Pro Pedal Set Wireless System...
Operating Operating 6.1 Receiver Normal operation Turn the jog wheel or press the foot switch repeatedly until the desired transmitter 1, 2, or 3 is selected. The display shows the settings of this transmitter (programme). The LEDs light up in the colour which corresponds to this transmitter.
Page 23
Operating Programming mode Use the jog wheel or the foot switch to select the transmitter which settings you want to edit. Press [SET/HOME] to switch to the programming mode. Turn the jog wheel until the desired menu item is highlighted on the display. Press the jog wheel to call up the menu item.
Page 24
Operating The following table shows the setting options in the menu. Menu item Value range Meaning ‘AntiFBACK’ 32 Hz… 330 Hz Feedback filter Selecting one of 31 frequencies to be attenuated to avoid whistling noise caused by acoustic feedback. ‘CableTone’ 10 ' (3 m)…100 ' (30 m) Selecting a virtual cable length to simulate the influences of a traditional cable on the transmission between instrument and...
Page 25
Operating Menu item Value range Meaning ‘SetColor’ ‘Green’ , ‘Red’ , ‘Blue’ , ‘Orange’ , Selecting a colour for the LEDs. ‘Purple’ , ‘Aqua’ , ‘White’ , ‘Yellow’ ‘Channel Scan’ Starts a check of the available radio channels. The display shows the result with a graphical representation.
Page 26
Operating Creating a programme Press [SET/HOME] to switch to the programming mode. Turn the jog wheel until the [New?] menu item is highlighted on the display. Press the jog wheel to call up the menu item. Set the required parameters. Turn the selection wheel and press ‘Rename? è...
Operating 6.2 Transmitter Putting the transmitter into service Connect the transmitter to your instrument before switching the transmitter on. If the transmitter is not going to be connected directly to the instrument, use the screw-type extension cable. Use the practical metal clip to fix the transmitter at the guitar strap. Press [ON].
Page 28
Operating Battery replacement Turn the transmitter off. Press the snap lock forward to open the battery compartment cover. Remove the empty battery and replace it with a charged one. Observe the correct polarity. The positive pole points into the device in the direction of the phone socket. Close the battery compartment and turn the transmitter back on.
Technical specifications Technical specifications 7.1 Receiver Number of systems that can be oper‐ 8 systems ated in parallel Input connections Power supply Socket for connecting the power adapter Output connections Line output 1× XLR panel plug, balanced 2× 6.35-mm jack socket, unbalanced Tuner output 1×...
Page 30
Technical specifications Audio sampling rate 24 bit / 44.1 kHz Power consumption 1.6 W Operating voltage 9- 12 V / 1,000 mA, centre positive or centre negative Installation properties 19 inches, 1 RU Dimensions (W × H × D, without 110 mm ×...
Technical specifications 7.2 Transmitter Frequency range 2.400 GHz … 2.4835 GHz Max. transmission power 10 mW Maximum input level 6.5 dBV Bandwidth 2.4 GHz Modulation type Frequency shift keying (FSK) Input impedance 1.0 MΩ Range in clear field of vision up to 100 m NF frequency response 20 Hz…20 kHz...
Technical specifications Dimensions (W × H × D, without 84 mm × 35 mm × 29 mm antenna) Weight 61 g Ambient conditions Temperature range 0 °C…40 °C Relative humidity 50% (non-condensing) 7.3 Battery charging station Battery Battery type Lithium-ion rechargeable battery ICR-18500 Voltage 3.7 V...
Page 33
Technical specifications Ambient conditions Temperature range 0 °C…40 °C Relative humidity 50% (non-condensing) Further information Frequency band 2.4 GHz Diversity Switchable frequencies Detachable antennas Pilot tone Max. number of radio links Power supply of the transmitter Battery GigA Pro Pedal Set Wireless System...
Page 34
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
Page 35
Plug and connection assignment 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (mono, bal‐ anced) Signal (in phase, +) Signal (out of phase, –) Ground XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) GigA Pro Pedal Set Wireless System...
Page 36
Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Symptom Remedy No sound 1. Check the power supply of the transmitter and receiver. 2. Make sure that transmitter and receiver are operating in the same frequency range.
Page 37
3. Interference can also be caused by other radio or in-ear systems. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. GigA Pro Pedal Set Wireless System...
Page 38
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
Page 39
When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
Page 40
Notes GigA Pro Pedal Set Wireless System...
Page 41
Notes GigA Pro Pedal Set Wireless System...
Page 42
Notes GigA Pro Pedal Set Wireless System...
