- Page 1 INSTALLATION & USER GUIDE For Routing Infrared Commands from Four IR Receivers to Eight Sources IR-CB4 FOUR ZONE IR CONNECTING BLOCK...
-
Page 2: Table Of Contents
IR-CB4 FOUR ZONE IR CONNECTING BLOCK TABLE OF CONTENTS Features...1 Product Overview...2 Package Contents ...4 Preparing for Installation...4 Installation...4 Troubleshooting ...7 Specifications ...9 Warranty...10... -
Page 3: Features
FEATURES Provides four IR receiver inputs and eight IR emitter outputs Two selectable high/low emitter outputs for use with IR-E1HO high output emitter or single and dual emitters LED power indicator 3.5mm 12V DC output jack triggered by sensing status or discrete IR commands Contact closure triggered by sensing status or discrete IR commands 12V DC status input jack and LED indicator Installation friendly design:... -
Page 4: Product Overview
PRODUCT OVERVIEW Figure 1... - Page 5 NC (normally closed) contact closure device to the IR-CB4. 9. Receiver Input – Four position quick connect plug for connecting IR receiver to the IR-CB4. 10. Receiver Input Labels – Recessed label slot for installation of preprinted room...
-
Page 6: Package Contents
Wire labels INSTALLATION 1. Select an appropriate location for the IR-CB4. 2. Run all the necessary wiring to the IR-CB4. Label the wires for future reference. 3. Plug the supplied 12V DC power supply into the un- switched AC outlet. -
Page 7: Installation Diagram
10. Insert the smooth side of the connector plug into the smooth side of the IR-CB4 socket. 11. Connect the emitters to the emitter outputs. 12. Plug the 12V DC power supply connector into the IR-CB4 socket marked POWER. - Page 8 AC power outlet of the preamp/receiver to the status input jack of your IR-CB4. Any 12V DC power supply with a minimum of 100mA current capacity can be used. See figure 2. Hi / Low Emitter Output Switches Emitter Output positions 7 and 8 have Hi / Low output options.
-
Page 9: Troubleshooting
Contact Closure The JobSite IR-CB4 provides a contact closure that can be triggered one of two ways: 1. The presence of status voltage on the 3-30V AC/DC status input jack. 2. Discrete infrared on and off commands. Set the contact closure... - Page 10 IR Saturation Sometimes the emitter output can saturate the IR receiving window of a component. When this occurs, the IR command will not be executed. This can occur on an intermittent basis when there is a Plasma TV in the system. Solution: 1.
-
Page 11: Specifications
Replace any IR-E1HO “flooding Emitter” with IR-E1 or IR-E2 Emitters and cover all Emitters with the supplied IR Blocking Covers. SPECIFICATIONS IR system: Works with all JobSite IR Receivers, single and dual IR Emitters Connections: 4 Receiver Inputs, 8 Emitter Outputs, 1 12V DC output... -
Page 12: Warranty
This Warranty is subject to the following additional conditions and limitations. The Warranty is void and inapplicable if JOBSITE deems that the product has been used or handled other than in accordance with the instructions provided by the manufacturer,... - Page 13 If the above conditions are met, the purchaser’s sole remedy shall be to return the product to JOBSITE, in which case JOBSITE will repair or replace, at its sole option, the defective product without charge for parts or labor. JOBSITE will...
- Page 14 NOTES ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________...
- Page 15 NOTES ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________...
- Page 16 WWW.JOBSITESYSTEMS.COM © 2004 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite products (or components thereof) are manufactured under one or more U.S.
