Jobsite IR-SMR MKII Datasheet

Jobsite ir-smr mkii: specifications.

DATA SHEET

For Receiving and Routing

Infrared Commands from

Any Remote Control

IR-SMR MKII

LCD/PLASMA-PROOF SURFACE MOUNT IR RECEIVER

Receiver Jobsite IR-SMR User Manual
Jobsite ir-smr: user guide (2 pages)
Receiver Jobsite IR-CB1 Installation & User Manual
One zone ir connecting blocks, for routing infrared commands from one ir receiver to four sources (12 pages)
Receiver Jobsite IR-CB2 Installation & User Manual
Two zone ir connecting blocks, for routing infrared commands from two ir receivers to five sources (12 pages)
Receiver Jobsite IR-CB4 Installation & User Manual
Four zone ir connecting blocks, for routing infrared commands from four ir receivers to eight sources (16 pages)

Receiver Jobsite IR-WMR Installation And User Manual
Jobsite ir-wmr: user guide (12 pages)
Receiver Jobsite IR-WMR MKII Datasheet
Jobsite ir-wmr mkii: specifications (4 pages)
Receiver Jobsite M-64 Installation & User Manual
Multizone receiver, for playing four sources in six separate zones (47 pages)

Page 1

DATA SHEET For Receiving and Routing Infrared Commands from Any Remote Control IR-SMR MKII LCD/PLASMA-PROOF SURFACE MOUNT IR RECEIVER...
Page 2

• Self-adhesive, surface mount DIMENSIONS: • 2” (50.8 mm) wide x 11/16” (17.5 mm) high x 1/2” (12.7 mm) deep WARRANTY: • 2 year limited LCD/PLASMA-PROOF SURFACE MOUNT IR RECEIVER IR-SMR MKII BLACK PART# FG01454 IR-SMR MKII SILVER PART# FG01455 IR-SMR MKII...
Page 3

PREPARING FOR INSTALLATION: The IR-SMR MKII Receiver cable must reach the proposed location of the IR Connecting Block. If not, use Category 5 cable to extend the length. Mark the cable with a Wire label, describing where the cable originates from, rather than where it will terminate.
