- Page 1 INSTALLATION & USER GUIDE For Receiving and Routing Infrared Commands from any Remote Control IR-WMR PLASMA-PROOF WALL MOUNT IR RECEIVER...
-
Page 2: Table Of Contents
IR-WMR PLASMA-PROOF WALL MOUNT IR RECEIVER TABLE OF CONTENTS Features...1 Product Overview...2 Package Contents ...3 Preparing for Installation...3 Installation...3 Operation...5 Troubleshooting ...5 Specifications ...7 Warranty...8... -
Page 3: Features
FEATURES Plasma-proof design Rejects interference from flat panel displays, CFL lighting or indirect sunlight Works with practicality all remotes Extended receiving range Green talkback LED indicates when A/V system is on Blue talkback LED confirms reception of IR signals Installation friendly design: Snap and lock connector secures wire in place without the use of a screwdriver Includes Decora ®... -
Page 4: Product Overview
PRODUCT OVERVIEW Figure 1 (a) Electrical Box (b) Category 5 cable (c) IR-WMR IR Receiver (supplied) (d) Snap-on Color Insert (supplied) (e) Device Screws (2 supplied) (f) Decora® style Faceplate (supplied) (g) Faceplate Screws (2 supplied) -
Page 5: Package Contents
Device Mounting Screws x 2 Faceplate Screws x 2 PREPARING FOR INSTALLATION If you are installing the IR-WMR into an existing wall, take time to consider any possible obstructions which may be hidden inside the wall, such as wood or metal studs, electrical, telephone or other types of wiring, plumbing, AC or heating conduit. - Page 6 Installation Note The talkback LED can be disabled if it continues to flicker or visual feedback is not desired. Discrete on and off IR commands are available on the JobSite Technical support website for disabling the talkback LED. The address is: www.jobsitesystems.com/techsupport/...
-
Page 7: Operation
Operation of the IR-WMR is simple. Stand within the operational range of your IR-WMR. Aim your hand- held remote at the IR-WMR and press the button for Suggested wiring of WMR to a RJ45 connector for connection to a JobSite M-4KP keypad. - Page 8 IR-E2 Emitters and cover all Emitters with the supplied IR blocking covers. Identifying the type of interference: The “Talkback” LED on the front of the IR-WMR is a useful trouble- shooting aid. The LED should light blue only when a remote command is being received.
-
Page 9: Specifications
There are many methods for reducing interference. Which solution is best for you depends on your situation. If you require further assistance contact JobSite Technical Support at 1-866-458-7483. SPECIFICATIONS IR system: Works with practically all brands of IR remote controls IR receiving (varies by brand of remote control): 18’-30’... -
Page 10: Warranty
JOBSITE or an authorized JOBSITE wholesale distributor. To obtain warranty service, you must write to... - Page 11 SHIPPING INSTRUCTIONS FROM JOBSITE. If the above conditions are met, the purchaser’s sole remedy shall be to return the product to JOBSITE, in which case JOBSITE will repair or replace, at its sole option, the defective product without charge for parts or labor.
- Page 12 WWW.JOBSITESYSTEMS.COM © 2004 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite products (or components thereof) are manufactured under one or more U.S.
