Procom NVDWA1 Instructions Manual page 5

4. Install valve cover (L) to burner pan using
two self tapping screws (K) as shown in Fig. 4.
5. Install safety pilot (C) and piezo ignitor (M)
onto valve cover (L) as shown in Fig. 5. Use two
self tapping screws (K).
6. Install the control knob (E) to the control rod
extension (F). Push the control rod extension (F)
onto the "D" shaped control rod through the
center hole in the cover as shown in Fig. 6.
K
L
K
L
E
5
Fig. 4
Fig. 5
C
M
Fig. 6
L
F
