MK-1945-24
Part #
MK-1945-24
Assembly Instructions
Tools Needed:
- 9/16" Wrench or socket
- 5/8" Wrench or socket
- 5/16" Wrench or socket
PART
PART
LETTER
A
B
C
D
E
F
G
I-00153
Instruction #
MK-1945-24
Part #
1 of 4
Page:
Voice 973-839-1011
Fax
973-839-1976
Instruction #
PART
NUMBER
SAN
NUT, # 8-32 ACORN
3/8AN
NUT, 3/8-16 ACORN
92-012
NUT, 3/8-16 FLANGE
92-011
BOLT, 3/8-16,HEX
500-00166 HOLE PLUG, NYLON,
1.75", BLACK
MK Series
CABLE MANAGEMENT
Cable Ring
RING
GK4
CABLE GROMMET RING,
4 PIECES
B
Rev.
Assembly:
I-00153
DESCRIPTION
Date:
full
middleatlantic.com
Rev.
PATENT PENDING
QTY.
40
28
28
8
16
40
1
5/05/05
B
Advertisement
Related Manuals for Middle Atlantic Space MK Series
Summary of Contents for Middle Atlantic Space MK Series
- Page 1 Rev. MK-1945-24 I-00153 Part # Instruction # PATENT PENDING MK-1945-24 Assembly Instructions Tools Needed: - 9/16" Wrench or socket - 5/8" Wrench or socket - 5/16" Wrench or socket PART PART PART DESCRIPTION QTY. NUMBER LETTER IMAGE NUT, # 8-32 ACORN 3/8AN NUT, 3/8-16 ACORN 92-012...
- Page 2 1) Assemble sides to bottom as shown NOTE: Sides are the same and can be assembled in either direction 2) Assemble sides to top as shown 2 of 4 full Page: Assembly:...
- Page 3 4) Install hole plug and cable ring as shown 5) Install GK4 grommet rings where cable may pass-through, as shown NOTE: 4 pieces GK4 grommet rings included. Order Middle Atlantic Products part # GK4 for more, includes 4 pieces grommet rings 3 of 4 full...
- Page 4 To gang racks, install hardware supplied in 8 locations shown Install ganging hardware in 8 circled locations To install grommet rings, pull open flange and insert bottom edge into cable pass-through holes. Firmly press grommet into position, working your way around until fully inserted SIDE VIEW Inside of rack frame...
