THANK YOU
Thank you for purchasing the Essex MMR Series Multi Mount Rack.
Please read these instructions thoroughly before installing / assembling this product.
PRODUCT FEATURES
• Multi-purpose design allows for wall mount or floor standing
• Optional quick hang bracket or pivot backpan for easy access to rear of equipment
• Optional active cooling
• Optional locking casters
Instruction Sheet
MMR Series
Essex Multi Mount Rack
I-00676
Rev -
Advertisement
Table of Contents
Related Manuals for Middle Atlantic Essex MMR Series
Summary of Contents for Middle Atlantic Essex MMR Series
- Page 1 MMR Series Essex Multi Mount Rack THANK YOU Thank you for purchasing the Essex MMR Series Multi Mount Rack. Please read these instructions thoroughly before installing / assembling this product. PRODUCT FEATURES • Multi-purpose design allows for wall mount or floor standing •...
-
Page 2: Important Safety Instructions Pages
IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. WARNING: WARNING INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, • Keep these instructions. COULD RESULT IN DEATH OR SERIOUS INJURY. • Heed all warnings. CAUTION: CAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, •... - Page 3 CONSIGNES DE SÉCURITÉ IMPORTANTES • Lisez attentivement ces instructions. AVERTISSEMENT: AVERTISSEMENT INDIQUE UNE SITUATION POTENTIELLEMENT DANGEREUSE • Conservez ces instructions à portée de la main. SUSCEPTIBLE, SI ELLE N'EST PAS ÉVITÉE, DE PROVOQUER LE DÉCÈS OU UNE BLESSURE GRAVE. • Prêtez attention à tous les avertissements. ATTENTION: ATTENTION indique une situation •...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions Pages 2-3 Regulatory Compliance Pages 2-3 Weight Ratings Pages 2-3 Tools Required Page 5 Hardware / Items Supplied Page 5 Mounting Dimensions Page 6 Wall Mount Installation Page 7 Optional Hang Bracket Installation Page 8 Optional Hang Bracket Installation (Continued) Page 9 Optional Backpan Installation (Continued) -
Page 5: Tools Required
TOOLS REQUIRED • #2 Phillips Screwdriver • Adjustable Wrench • 1/2” Socket HARDWARE/ITEMS SUPPLIED NOTE: Additional hardware may be included which may not be required for your installation. Bolts Washers 1/2”-13 x 3/4” (Qty 2) (Qty 2) [Hang Bracket / Backpan Installation] [Hang Bracket / Backpan Installation] Security Screw 10-32 x 3/4”... -
Page 6: Mounting Dimensions
MOUNTING DIMENSIONS (WALL MOUNT INSTALLATION) MMR-1820 MMR-1620 MMR-1220 MMR-1020 MMR-1824 MMR-1624 MOUNTING DIMENSIONS (HANG BRACKET INSTALLATION) HANG-MMR18 HANG-MMR16 HANG-MMR12 HANG-MMR10 MOUNTING DIMENSIONS (BACKPAN INSTALLATION) PIVOT-MMR-18 PIVOT-MMR-16 PIVOT-MMR-12 PIVOT-MMR-10 Page 6... -
Page 7: Wall Mount Installation
WALL MOUNT INSTALLATION NOTE: THE CABINET MUST BE INSTALLED PLUMB AND LEVEL FOR PROPER OPERATION. NOTE: A sheetrock wall mounted to wood studs on 16” centers is required for installation. 1) Locate studs behind sheetrock wall. 2) Align rear mounting holes in rack with studs. Refer to Mounting Dimensions on Page 6 for mounting hole locations. -
Page 8: Optional Hang Bracket Installation
OPTIONAL HANG BRACKET INSTALLATION (HANG-MMRXX) NOTE: THE CABINET MUST BE INSTALLED PLUMB AND LEVEL FOR PROPER OPERATION. NOTE: A sheetrock wall mounted to wood studs on 16” centers is required for installation. 1) Locate studs behind sheetrock wall. Hang Bracket Slots 2) Align rear mounting holes in hang bracket with studs. -
Page 9: Optional Hang Bracket Installation (Continued)
OPTIONAL HANG BRACKET INSTALLATION (CONTINUED) 5) Secure rack to hang bracket using (2) 1/2”-13 bolts with washers and (1) 10-32 x 3/4” security screw with washer. (FIGURE D) Washers (Qty 2) FIGURE D Security Screw 10-32 x 3/4” with Washer (Qty 1) Bolts 1/2”-13 x 3/4”... -
Page 10: Optional Backpan Installation (Continued)
OPTIONAL BACKPAN INSTALLATION (PIVOT-MMR-XX) NOTE: THE CABINET MUST BE INSTALLED PLUMB AND LEVEL FOR PROPER OPERATION. NOTE: A sheetrock wall mounted to wood studs on 16” centers is required for installation. 1) Locate studs behind sheetrock wall. 2) Align rear mounting holes in backpan with studs. Refer to Mounting Dimensions on Page 6 for mounting hole locations. -
Page 11: Optional Backpan Installation (Continued)
OPTIONAL BACKPAN INSTALLATION (CONTINUED) 4) Insert bushing in upper pivot bushing hole on top of rack. (FIGURE F) 5) Lift rack and place bottom on the edge of backpan. Position rack so as to engage the lower pivot bushing on backpan. (FIGURE G) 6) Thread lower pivot pin into lower pivot bushing. -
Page 12: Grounding And Bonding
GROUNDING AND BONDING Protective Earth Terminals (PET) are located in the backpan, center section and hang bracket. These terminals are marked with the symbol Wall rack parts, center section and door, contain or are provided with bonding points for connection to the backpan / PET. Protective earth and bonding connections shall be in accordance with Article 250 of the National Electric Code. - Page 13 WARRANTY Middle Atlantic Products (the "Company") warrants the ESSEX MMR SERIES MULTI MOUNT RACK to be free from defects in material or workmanship for the lifetime of the product. The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and exclusive remedy, under this warranty...
