Adjustable Pole 12" To 72"
THANK YOU
Thank you for purchasing the VDM-A 12" to 72" adjustable pole series. Please read these
instructions thoroughly before installing or assembling this product.
PRODUCT FEATURES
• 1 1/2" NPSM threads on both ends
• 500 lb. weight capacity
• Adjustable pole length
Instruction Sheet
VDM-A Series
MODEL NUMBERS
•
VDM-A-12-18-BK
•
VDM-A-18-24-BK
•
VDM-A-24-36-BK
•
VDM-A-36-60-BK
•
VDM-A-48-72-BK
I-00833
Rev -
Advertisement
Table of Contents
Related Manuals for Middle Atlantic VDM-A Series
Summary of Contents for Middle Atlantic VDM-A Series
- Page 1 Instruction Sheet VDM-A Series Adjustable Pole 12” To 72” MODEL NUMBERS • VDM-A-12-18-BK • VDM-A-18-24-BK • VDM-A-24-36-BK • VDM-A-36-60-BK • VDM-A-48-72-BK THANK YOU Thank you for purchasing the VDM-A 12” to 72” adjustable pole series. Please read these instructions thoroughly before installing or assembling this product.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. • Heed all warnings. • Clean only with dry cloth. • Keep these instructions. • Follow all instructions. • Only use attachments/accessories specified by the manufacturer. DANGER HAZARDOUS VOLTAGE: The lightning flash with the WARNING: A warning alerts you to a situation that could result arrowhead symbol, within an equilateral triangle is intended to alert the in serious personal injury or death. -
Page 3: Weight Ratings
WEIGHT RATINGS Model Product Weight Weight Rating VDM-A-12-18-BK 4.0 lbs. (1.81 kg) 500 lbs. (226.8 kg) Maximum Total Rated Load VDM-A-18-24-BK 6.0 lbs. (2.72 kg) 500 lbs. (226.8 kg) Maximum Total Rated Load VDM-A-24-36-BK 8.0 lbs. (3.63 kg) 500 lbs. (226.8 kg) Maximum Total Rated Load VDM-A-36-60-BK 12.0 lbs. - Page 4 ASSEMBLING ADJUSTMENT TUBE 1. Slide end of extension pipe (A) with tapped holes into adjustment tube (B). (FIGURE A) Tapped Holes FIGURE A 2. Thread button head screw (D or E) into slot in adjustment tube (B), but do not tighten. (FIGURE B) 3.
- Page 5 ASSEMBLING ADJUSTMENT TUBE (CONTINUED) 6. Insert (2x) set screws (F or G) into adjustment tube (B) and tighten to secure extension pipe (A) in place. (FIGURE C) NOTE: Hex wrench supplied can be used for both standard and security set screws. F or G FIGURE C Page 5...
-
Page 6: Warranty
- customerservicecanada@middleatlantic.ca Factory Distribution USA: NJ - CA - IL Canada: ON - BC At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company. Page 6...
