THANK YOU
Thank you for purchasing the RM-LCD Series LCD Rackmount. Please read these instructions
thoroughly before installing/assembling this product.
RM-LCD-MV LCD SCREEN INSTALLATION.....................................................................Page 2
RM-LCD-MK LCD SCREEN INSTALLATION.....................................................................Page 3 - 5
RM-LCD-MT LCD SCREEN INSTALLATION.....................................................................Page 5 - 6
Positioning Monitor Depth.....................................................................................Page 6
Instruction Sheet
RM-LCD-MX
RM-LCD Series
TABLE OF CONTENTS
I-00372
Rev -
Advertisement
Table of Contents
Related Manuals for Middle Atlantic RM-LCD Series
Summary of Contents for Middle Atlantic RM-LCD Series
- Page 1 Instruction Sheet RM-LCD-MX RM-LCD Series THANK YOU Thank you for purchasing the RM-LCD Series LCD Rackmount. Please read these instructions thoroughly before installing/assembling this product. TABLE OF CONTENTS RM-LCD-MV LCD SCREEN INSTALLATION..............Page 2 RM-LCD-MK LCD SCREEN INSTALLATION..............Page 3 - 5 RM-LCD-MT LCD SCREEN INSTALLATION..............Page 5 - 6...
- Page 2 SUPPLIED HARDWARE (All Models) (4) # 2 Phillips Head VESA Mounting Screws NOTE: The center frame comes from the factory in the forward most position. INSTALLATION OF LCD SCREEN (Model RM-LCD-MV) 1) Install monitor into VESA holes using provided screws. VESA 75 MOUNTING HOLES VESA 100 MOUNTING HOLES Page 2...
- Page 3 INSTALLATION OF LCD SCREEN (Model RM-LCD-MK) NOTE: The LCD screen can be mounted using two methods. METHOD ONE 1) Detach the VESA mount from the frame by removing the six 1/2” bolts and wing nuts. 2) Attach monitor to corresponding VESA holes with provided screws. 3) Reattach the VESA mount/monitor to the frame using previously removed bolts and nuts.
- Page 4 INSTALLATION OF LCD SCREEN (Model RM-LCD-MK Continued) 3) Rotate the monitor 180 degrees (the monitor/VESA mount rotates left and right). (FIGURE C) FIGURE C 4) Install the other two provided mounting screws into the top of the monitor. (FIGURE D) FIGURE D Page 4...
- Page 5 INSTALLATION OF LCD SCREEN (Model RM-LCD-MK Continued) 5) Adjust the monitor to the desired position. 6) Using a 1/2” wrench, tighten the bolts that control vertical and horizontal positioning. (FIGURE E) VERTICAL ADJUSTMENT BOLT HORIZONTAL ADJUSTMENT BOLT FIGURE E INSTALLATION OF LCD SCREEN (Model RM-LCD-MT) 1) Install the monitor to the VESA mount on the end of the arm using provided screws.
- Page 6 WARRANTY Middle Atlantic Products, Inc. (the "Company") warrants the RM-LCD-MV to be free from defects in material or workmanship under normal use and conditions for the lifetime of the product, three (3) years for the RM-LCD-MK/RM-LCD-MT from shipment from the company.
