Manufactured for Rooms To Go
IMPORTANT: ASSEMBLING THIS UNIT NEEDS MINIMUM 2 PERSONS
NO.
Description
A
Backrest
B
Seat
Wall plug
C
transformer
D
Wood Leg
E
Plastic Leg
F
Bolt
ASSEMBLY INSTRUCTION
DUAL POWER RECLINER
HLVN 7105R1 / 7105R2 / 7105R3
LIST OF PARTS
Item
Quantity
1
1
1
4
4
16
HLVN
7105R1-19
15471559
7105R2-19
15471561
7105R3-19
15471573
SKU:
Advertisement
Table of Contents
Related Manuals for ROOMS TO GO HLVN 7105R1-19
Summary of Contents for ROOMS TO GO HLVN 7105R1-19
- Page 1 ASSEMBLY INSTRUCTION DUAL POWER RECLINER HLVN 7105R1 / 7105R2 / 7105R3 Manufactured for Rooms To Go IMPORTANT: ASSEMBLING THIS UNIT NEEDS MINIMUM 2 PERSONS HLVN SKU: 7105R1-19 15471559 7105R2-19 15471561 7105R3-19 15471573 LIST OF PARTS Description Item Quantity Backrest Seat...
- Page 2 ASSEMBLY INSTRUCTIONS Step 1: Take out carefully the back cushions & inner carton from the packing. Step 2: With seat cushion facing upside down. Attach 4 pcs wood legs (using 4 bolts per leg) & turn 4 pcs plastic legs clockwise until it has been completely screwed in. Metal plate have to be aligned in a certain direction as shown in the following pictures.
- Page 3 ELECTRICAL CONTROLS 1 Press button to recline the recliner to desired position 2 Press button to raise the recliner to the upright position. 3 Press button to activate the headrest forward. 4 Press button to return headrest to the closed position. 5 Press home button returns both footrest and headrest to the original upright or closed position.
- Page 4 CARE AND CLEANING * Upholstered furniture is packaged tightly to protect it during transsit. This packaging can sometimes cause creases or misshaped cushions when the furniture comes out of the packaging. These issues will correct themselves over time as the fibers of the cushions are exposed to air. However, shaping the cushions with your hands can alleviate the creases and compressed fibers more quickly.
