Identify All Parts Packed In The Carton Against The Parts List. Remove All
Protective Materials.Place Parts On A Non-abrasive Surface To Avoid
Scratching.Do Not Attempt Assembly If Any Parts Are Missing Or Damaged.
Warning: Please Do Not Use Acid Or Alkaline Washing Liquid To Clean The Product.
Chairs have a 300 lbs weight capacity.
Assemble The Product As Below Shown Step By Step
Part List
SKETCH
NO.
A
Swivel Base
B
Seat Cushion
C
D
Back Cushion
E
Assembly Instructions
MONTARA SWIVEL CLUB CHAIR
SKU#
DESCRIPTION
QTY
Seat Frame
1
1
1
1
4
Foot Glider
71563122
SKETCH
NO.
AA
BB
CC
DD
EE
FF
GG
HH
DESCRIPTION
QTY
Bolt
4
(M8*55)
Steel Washer
8
(Φ12.5*Φ8.5*2)
Steel Washer
8
(Φ16*Φ8.2*1.0
)
4
Steel Washer
4
Nut
Bolt Cap
4
(19*16.5*11.5)
Bolt Cap
4
(19*16.5*17)
2
Wrench
GLA-63127-31KD
Made in China
1
Advertisement
Table of Contents
Related Manuals for ROOMS TO GO MONTARA 71563122
Summary of Contents for ROOMS TO GO MONTARA 71563122
- Page 1 Assembly Instructions MONTARA SWIVEL CLUB CHAIR SKU# 71563122 Identify All Parts Packed In The Carton Against The Parts List. Remove All Protective Materials.Place Parts On A Non-abrasive Surface To Avoid Scratching.Do Not Attempt Assembly If Any Parts Are Missing Or Damaged. Warning: Please Do Not Use Acid Or Alkaline Washing Liquid To Clean The Product.
- Page 2 STEP 1 Hand-tighten nuts 3-4 revolutions only. After attaching all bolts, adjust all parts at the correct position. Then tighten all bolts and nuts. Do Not Over Tighten. СС STEP 2 Turn the chair right side up. Adjust the pre-installed foot glider(E) at the bottom of swivel base until the chair is level with the ground securely, your chair is ready for use.
