Assembled View
2
Parts List
Parts in Box A:
A
B
C
Headboard
Post
(Left Hand)
x 1
Parts in Box C:
0070 Full Bed
Assembly Instructions
Headboard Panel x 1
Headboard Support x 1
Headboard
(Right Hand)
G
Footboard Panel x 1
H
Side Rail x 2
J
Long Support x 1
Parts in Box B:
(Left Hand) x 1
D
Post
x 1
M
Support
Leg x 3
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
E
Headboard
Side Panel
(Right Hand) x 1
K
Footboard
Post
(Left Hand)
x 1
N
Set of Bed Slats x 1
WI-0521
Use 2 People
F
Headboard
Side Panel
L
Footboard
Post
(Right Hand)
x 1
Page 1 of 7
