- Page 1 QUICK START GUIDE Visit fjwestcott.com/firmware for firmware information.
- Page 2 Visit fjwestcott.com/documentation and scroll to the L60-B section to download the complete User Manual. Included Components & Overview L60-B COB LED, AC Power Adapter & Cord, 45° Ultra Reflector, Protective Cover, Travel Case, Rapid Box Switch Insert Components may vary depending on the kit purchased.
- Page 3 2. Plug the two-prong connector of the cable into a wall outlet. 3. Locate the barrel plug on the AC cable and plug it into the L60-B power port. 4. Ensure that the clear protective cover has been removed from the front of the L60-B.
- Page 4 Bluetooth Intensity Controls Adjusting the Light Output 1. Ensure that the L60-B is ON. 2. Turn the Dim•Bluetooth control knob to adjust the light output. Adjusting the Color Temperature (Kelvin) 1. Ensure that the L60-B is ON. 2. Turn the CCT•FX control knob to adjust the color temperature.
- Page 5 1. Rotate the yoke’s light stand tension knob counterclockwise to loosen. 2. Insert the light stand spigot into the L60-B’s 5/8"-16 mm receiver. 3. Tighten the tension knob to secure the L60-B to the light stand. Attaching & Removing Modifiers The L60-B is compatible with various Rapid Box Switch light modifiers up to 3 lbs / 1.4 kg using the included Switch Insert.
- Page 6 (“Warranty Period”). If a defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, Westcott will either (1) repair the defect at no charge, using new or refurbished replacement parts, or (2) exchange the product with a product that is new or which has been manufactured from new or serviceable used parts and is at least functionally equivalent to the original product.
