Westcott 8001 Setup Instructions

Setup Instructions

Universal Clamp

Style Series: 8001

Description

A quick solution when an umbrella receptacle is not available.

Product Contains

[1] Hose Clamp
[1] Black Block with thumb screw

INSTRUCTIONS

NOTE: The Bracket Hose Clamp comes in a
variety of sizes up to 8" which is adaptable to
most shapes and can be purchased at your local
automotive supply or hardware stores. (Ideal
or Dixon clamps work best)
1. The hose clamp is to slide completely
around the front section of the lighting unit.
2. When in place, insert the Bracket under the
Hose Clamp (In the Harness Position)
3. Use a screwdriver to then tighten. Finally,
insert umbrella shaft through mount until
desired position is established, then tighten
Set Screw Knob.
NOTE: When attaching to a portable Strobe,
follow the above instructions for assembly and
choose the required Hose Clamp size for your
Strobe.
Questions? Please call 800.886.1689 or email .
