- Page 1 Denago Quickstart Guide Denago by Bike.com...
- Page 2 Denago Our team has always loved the striking features of Denali and it’s meaning “The Great One” in the native language of Kouyukon Athabascan. We hope you enjoy your ride… wherever you go.
- Page 3 THANK YOU and welcome to the Bike.com team. We value and appreciate you and your choice. If there is anything you need, please reach out and let us know how we can help. Email: cs@bike.com Call Us: 877-755-2453 (BIKE)
-
Page 4: Always Wear A Helmet
ALWAYS WEAR A HELMET Ebikes are new to most riders, so in the interest of safe cycling please make sure you read, understand, and follow the instructions in this Quickstart Guide. For more information, please visit: www.Bike.com/support... - Page 5 Model 1...
- Page 7 The QUICKSTART GUIDE will assist you in completing the assembly By following the directions, you will be able to get outside and start riding your new Denago bike in less than 30 minutes If you are not comfortable or confident, please take your...
-
Page 8: Getting Started
Getting Started... - Page 9 Unpack and Unwrap your eBike...
- Page 10 Lay Out the Parts and Tools We’d like to make your assembly process a bit easier. So we made a Parts & Tools layout inside the box. Please lay Parts & Tools into each area.
-
Page 11: Assembly Steps
Assembly Steps 1. Handlebar 2. Seat 3. Front Wheel & Front Brake 4. Pedals 5. Adjustments... - Page 12 1. Handlebar...
- Page 13 Handlebar components has been pre-assembled 1. Unscrew bolt and remove 2. Place stem on steerer tube and 3. Place stem onto the head tube. cap, bolt, and sleeve. Leave tighten the bolt on top of stem to Align stem to the center position. all spacers in place.
- Page 16 2. Seat...
- Page 17 The seat was pre-assembled 1. Install Rear Reflector 2. Apply grease inside Seat 3. Place Seat Post inside (Red) to Seat Post Tube Seat Tube - Insert past MIN Insertion Marking CAUTION Make sure seat post is inserted to at least minimum insertion markings are NOT visible 4.
- Page 18 3. Front Wheel & Front Brake...
- Page 19 Your bike has a BOLT ON mechanism 1. Remove Packing Block from disc 2. Position the front wheel so it’s 3. Align the disc brake rotor so it is brake caliper – Do Not Throw Away centered between the front fork legs centered in the slot of the brake –...
- Page 20 Do NOT touch the brake rotor, especially while in motion. Be CAUTIOUS and do not allow oils to be applied or added to the DISC/ROTOR. This can cause squeaking and decrease braking performance. Improper installation of the front wheel and or handlebar stem can cause loss of control, accidents, serious injury or death.
- Page 21 4. Pedals...
- Page 22 MATCH PEDAL and CRANK ARM CAREFULLY Add grease to threads prior to installing Right pedal is applied to drive side/side with crank and gears and threads/twist on CLOCKWISE Left pedal is applied on NON-DRIVE side/side with disk rotors and twist COUNTERCLOCKWISE Use Pedal Wrench and Confirm Pedals are tightened and secure Check frequently ...
- Page 23 5. Adjustments...
- Page 24 Please confirm stem and front wheel are in alignment.
- Page 25 Owner’s Manual and more comprehensive details are available online. Please go to www.bike.com/support for content and video support You're almost finished, but now is the time for the final adjustments and safety check. Then you will be ready for a test ride.
- Page 26 Some other important things...
- Page 27 Battery Details You can charge your battery while it is in your bike. 1. Plug Charger into the PORT on the Battery 2. Plug Charger into the WALL OUTLET (110V) Only use factory supplied battery and battery charger. Failure to do so could result in damage, fire, serious injury or death. ...
- Page 28 Remove and Install the Battery Return Battery Lift Battery Out Unlock Lock & Confirm Press Battery at TOP Be careful. It is heavy until you hear click...
- Page 29 Intended Use and Safety Check...
- Page 30 Intended Use Your bike is intended to be ridden on paved roads. Please always wear a helmet and follow all local and common-sense safety. Perform a safety check Before and After EACH Ride Safety Check For your safety, please do the following inspection before and after each ride. If you discover any concerns with your bike, please seek professional service or contact ...
-
Page 31: Warranty Information
Warranty Information Owner’s Manual How-to Videos and more info Available at www.Bike.com/support If you need any help, please give us a call 877-755-2453 (bike) or email cs@bike.com...
