DENAGO CITY 2 Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

QUICKSTART
GUIDE
CITY MODEL 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CITY 2 and is the answer not in the manual?

Questions and answers

Related Manuals for DENAGO CITY 2

Summary of Contents for DENAGO CITY 2

  • Page 1 QUICKSTART GUIDE CITY MODEL 2...
  • Page 2 With over 100 years collectively in the bike industry, our team loves to share with you what we learned from riding, working in bike shops and working in the bike industry. We are looking forward to you joining us for a ride.
  • Page 3 THANK YOU and welcome to the Denago team. We value and appreciate you and your choice. If there is anything you need, please reach out and let us know how we can help. Email: cs@denago.com Call Us: 877-755-2453 (BIKE)

  • Page 4: Always Wear A Helmet

    ALWAYS WEAR A HELMET Please make sure you read, understand and follow the instructions in the quickstart guide as eBikes are new to most riders. For more information, please visit: denago.zendesk.com...

  • Page 5: City Model

    CITY MODEL 2 CITY MODEL 2 5 | DENAGO...

  • Page 6: What's In The Box

    WHAT’S IN THE BOX The following accessories are included with your 90% pre-assembled Denago bike. Multi Tool Pedal / Wheel Wrench Bicycle grease packet Pedal Battery Charger Battery Keys 6 | DENAGO QUICKSTART GUIDE...
  • Page 7 The quickstart guide will assist you in completing the assembly By following the directions, you will be able to get outside and start riding your new Denago eBike in less than 30 minutes. If you are not comfortable or confi dent, please take your...

  • Page 8: Getting Started

    GETTING STARTED...
  • Page 9 Unpack and Unwrap your eBike CITY MODEL 2 9 | DENAGO...
  • Page 10 We’d like to make your assembly process a bit easier. So we made a Parts & Tools layout inside the box. Please lay Parts & Tools into each area. Front Wheel Tool Set & Parts Pedals Other Stuff 10 | DENAGO QUICKSTART GUIDE...

  • Page 11: Assembly Steps

    ASSEMBLY STEPS 1. HANDLEBAR 2. SEAT 3. FRONT WHEEL & BRAKE 4. PEDALS 5. MONITOR...
  • Page 12 6. Upon final assembly, revisit this step position, tighten and fix the bolts on to confirm alignment with stem both sides of the handlebar. and front wheel. NOTE: BRACKET ON FRONT OF STEM ARE FOR AN AFTERMARKET FRONT HEADLIGHT. 12 | DENAGO QUICKSTART GUIDE...
  • Page 13 You will need the +/phillips screw driver in the multi tool to install. Front Reflector Installation. Remove the screw and place bracket over the handlebar on the left side closest to the monitor, if you are sitting on the seat. Tighten and secure the screw. CITY MODEL 2 13 | DENAGO...
  • Page 14 - Insert past MIN Insertion Marking. CAUTION Make sure seat post is inserted to at least minimum insertion markings are NOT visible 4. Adjust the seat height. Clamp secure/ tighten the quick release clamp. 14 | DENAGO QUICKSTART GUIDE...
  • Page 15 Tighten nuts securely to the fork dropouts 4. Tighten one axle nut part way then tighten the other nut, repeat until both sides are tightened securely. Be sure that the wheel is centered between the fork legs. 15 | DENAGO...
  • Page 16 WARNING Do NOT touch the brake rotor, especially while in motion. Be CAUTIOUS and do not allow oils to be applied or added to the DISC/ROTOR. This can cause squeaking and decrease braking performance. Improper installation of the front wheel and or handlebar stem can cause loss of control, accidents, serious injury or death.

  • Page 17: Pedals | Assembly

    1. NON Drive Side of Bike select L-Left pedal 2. Apply grease to pedal threads 3. Insert Pedal into Crank Arm/NON- Drive side and start to turn COUNTER CLOCKWISE. 4. Once hand tight apply pedal wrench to pedal and tighten and secure. CITY MODEL 2 17 | DENAGO...
  • Page 18 You have 4 settings, use the + - to toggle thru each screen and the M to move to the next setting. SETTING 1 – inCH: Wheel size setting. SETTING 3 – BL: This is screen brightness. Your Denago City 2.0 is 27.5. You have 3 levels. SETTING 2 – LS: Limited Speed.
  • Page 19 STEP 5 – Press M (MODE) for 2 seconds can adjust MAX speed. to return to main screen. You are ready to ride. Use the + - (UP/Down) to adjust MAX limit. Your range is 28 –11 mph as the lowest limit. CITY MODEL 2 19 | DENAGO...
  • Page 20 ASSEMBLY | MONITOR Denago City 2.0 PAS (Pedal Assist System) comes with the ability to set your MAX speed while also adjusting your PAS level speeds. Custom Pedal Assist Settings - The rider is able toadjust the MAX speed setting with 18 micro adjustments •...
  • Page 21 Owner’s Manual and more comprehensive details are available online. Please go to DENAGO.ZENDESK.COM for content and video support You’re almost finished, but now is the time for the final adjustments and safety check. Then you will be ready for a test ride.
  • Page 22 Press the M button until the monitor/display turns on. Check the PAS setting - Ideally you want to start in PAS0 or PAS1. See Speed Adjustment to help find your most comfortable setting. YOU ARE READY to RIDE. ENJOY! 22 | DENAGO QUICKSTART GUIDE...
  • Page 23 Keep battery and charger away from children. DO NOT ever cover the battery or charger. This could cause overheating and potential fire. DO NOT open the battery housing. You will void all warranties and potential for serious injury and or death could occur. 23 | DENAGO...
  • Page 24 Key is not needed to install battery. 4. Key is not needed to install battery but if in place remove 2. Place bottom of battery into frame cavity and enjoy the ride. and slide down to connect. 24 | DENAGO QUICKSTART GUIDE...
  • Page 25 2. Place bottom of battery into frame cavity 4. Key is not needed to install battery but if in place and slide down to connect remove and Enjoy the Ride CITY MODEL 2 25 | DENAGO...
  • Page 26 INTENDED USE AND SAFETY CHECK Warranty Information Owner’s Manual How-to Videos and more info Available at denago.zendesk.com If you need any help, please give us a call 877-755-2453 (bike) or email cs@denago.com...
  • Page 27 For your safety, please do the following inspection before and after each ride. If you discover any concerns with your bike, please seek professional service or contact us at CS@DENAGO.COM or 877-755-2453 (BIKE) to help resolve any issues. Make sure your battery is at FULL Charge.
