- Page 2 The manual contains important instructions for the safe use and longevity of your bike. If you need any type of support or warranty information for your Denago eBike, please reach out and let us know how we can help. Email: cs@denago.com Call Us: 877-755-2453 (BIKE)
-
Page 4: What's In The Box
WHAT’S IN THE BOX The following accessories are included with your 90% pre-assembled Denago eBike. To prepare for the assembly of your Denago eBike, fi rst take out all pieces from the box and remove all packaging. Open the accessory box and remove all tools, parts and everything else that’s inside of it. - Page 5 Saddle Frame Stem Handlebar Seat clamp QR Rear rack Tire Fork Motor Pedal Battery Front disc brake Kickstand Rear disc brake Chainring Crank...
-
Page 6: Always Wear A Helmet
YOUR DENAGO BIKE IS 90% ASSEMBLED This quickstart guide will assist you in completing the assembly of your new Denago eBike. By following these directions, you will be able to get outside and start riding your new Denago eBike in less than 30 minutes. - Page 7 HANDLEBAR Multi Tool 4 & 5mm allen key Handlebar components have been pre-assembled Please tighten and secure all bolts Using the 5mm allen key, unscrew the top Place stem and handlebar assembly on With the stem on the head tube, center the stem bolt from the steerer tube and remove steerer tube, replace top cap and bolt, and stem inline with the front wheel.
-
Page 8: Monitor Installation
Insert the bolts, tighten and secure. Light Installation Remove allen bolt and wrap bracket around center of stem. Reapply bolt and using the 4mm allen key tighten and secure. Adjust light angle for preference. HUNTING 1... - Page 9 SADDLE Bicycle Grease Packet Apply grease inside Seat Tube. Place Seat Post inside Seat Tube. Adjust the seat height. Secure clamp/tighten Insert past MIN Insertion Marking. and close the quick release clamp. Make sure seat post is insterted to at least the minimun insertion mark.
-
Page 10: Front Wheel / Brake
Check regularly that the front wheel Re-install Thru-axle from the non-drive side and handlebar stem are ALWAYS properly secure and in good working condition. and thread into the drive side. Tighten Thru-Axle to labeled torque (10-15NM). HUNTING 1... - Page 11 PEDALS Right pedal is applied to drive side/side with crank and gears and threads/twist on CLOCKWISE Left pedal is applied on NON-DRIVE side/side with disk rotors and twist COUNTER-CLOCKWISE Confi rm Pedals are tightened and secure, check frequently. Pedal / Wheel Wrench On Drive Side of bike select R-Right pedal.
-
Page 12: Battery Removal / Installation
Key is not needed to install battery. and push the top of the battery into the cavity to hear a click. Key is not needed to install to connect. battery but if in place remove. Enjoy the ride. HUNTING 1... -
Page 13: External Battery Installation
EXTERNAL BATTERY INSTALLATION Multi Tool 5mm allen key Battery keys Unscrew 4 M5 bolts. Take out the rubber plug. Take out the waterproof plug-in from inside the frame. Connect the waterproof plug in the Put waterproof plug-in back into bike, Install the base of battery with the 4 frame to the plug on the battery base. - Page 14 Display of battery capacity in real time Voltage indicator in voltage or in percent. Digital speed display. Power indicator in watts / amperes. Support level/ Walking assistance Data: Display data, which corresponds to the current mode KEY DEFINITION Light On/Off System On/Off Down HUNTING 1 Ok/Enter...
- Page 15 NORMAL OPERATION Switching the System ON/OFF Press and hold (>2S) on the display to turn on the system. Press and hold (>2S) again to turn off the system. If the “automatic shutdown time” is set to 5 minutes (it can be set with the “Auto Off ” function, See “AUTO OFF”), the display will automatically be turned off within the desired time when it is not in operation.
-
Page 16: Display Setting
(<0.5S) button to highlight “Brightness” in the Display settings menu. Then press <0.5S) to select. Then with the button choose between “100%” / “75%” / “50%” /” 30%”/”10%” . Once you have chosen your desired selection, press the (<0.5S) button to save and exit to the “Display setting” interface. HUNTING 1... -
Page 17: Deactivating The Password
“Password” Press the (<0.5S) button to choose Password in the menu. Then by briefl y pressing (<0.5S) to enter the password selection. Now again with the (<0.5S) buttons highlight “Start Password” and press the (<0.5S) button to confi rm. Now again using the (<0.5S) Button choose between “ON”... -
Page 18: Battery Charging
Keep battery and charger away from children. DO NOT ever cover the battery or charger. This could cause overheating and potential fi re. DO NOT open the battery housing. You will void all warranties and potential for serious injury and or death could occur. HUNTING 1... - Page 19 ALWAYS WEAR A HELMET Please make sure you read, understand and follow the instructions in the quickstart guide as eBikes are new to most riders. For more information, please visit: denago.zendesk.com...
- Page 20 ACCESSORIES - GEAR HAULER TRAILER More comprehensive detailed instructions on how install optional accessories are available online at DENAGO.ZENDESK.COM Using the 15mm wrench, secure and tighten Use the 6mm allen wrench from the Find the quick release skewer and the front...
- Page 21 Multi Tool 5 & 6mm allen key 15mm Wrench Next install the trailer to bike. Align the hitch to the frame threads. Leaving the kickstand down may help in aligning and holding the trailer steady. Secure and tighten the M10 bolts snuggly to the frame.
- Page 22 ACCESSORIES - HUNTING TRAILER More comprehensive detailed instructions on how install optional accessories are available online at DENAGO.ZENDESK.COM The axle has two threaded holes that will Install each wheel on to the end of each axle, The backboard will be attached to the frame need to be aligned with the holes on the notating the forward tread direction.
- Page 23 Multi Tool 5 & 6mm allen key Next install the trailer to bike. Align the hitch to the frame threads. Leaving the kickstand down may help in aligning and holding the trailer steady. Secure and tighten the M10 bolts snuggly to the frame.
- Page 24 SOME OTHER IMPORTANT THINGS Owner’s Manual and more comprehensive details are available online. Please go to DENAGO.ZENDESK.COM for content and video support You’re almost fi nished, but now is the time for the fi nal adjustments and safety check. Then you will be ready for a test ride.
-
Page 25: Safety Check
For your safety, please do the following inspection before and after each ride. If you discover any concerns with your bike, please seek professional service or contact us at cs@denago.com or 877-755-2453 (BIKE) to help resolve any issues. Make sure your battery is at FULL charge. -
Page 26: Warranty Information
WARRANTY INFORMATION OWNER’S MANUAL HOW-TO VIDEOS AND MORE INFO Available at denago.zendesk.com If you need any help, please give us a call 877-755-2453 (bike) or email cs@denago.com...
