GE 45133 User Manual

Wireless alarm system water leak sensor
Hide thumbs

Advertisement

Quick Links

Wireless Alarm System
Water Leak
Sensor
User's Manual
Choice
Choice
ALERT
ALERT
Control all Sensors
& accessories from
one location
45133

Advertisement

loading

  Also See for GE 45133

  Related Manuals for GE 45133

  Summary of Contents for GE 45133

  • Page 1 Wireless Alarm System Water Leak Sensor User’s Manual Choice Choice ALERT ALERT ™ ™ Control all Sensors & accessories from one location 45133...
  • Page 2: Table Of Contents

    Important Safeguards Introduction Installation Assigning a Sensor to a Zone Erasing a Sensor from a Zone Testing a Sensor or your system Low battery indicator Battery warnings F.A.Q.'S FCC Warning Table of Contents 9-10 1-1...
  • Page 3 Before connecting or operating the Water Leak Sensor, please read these instructions carefully and save this manual for future reference. Congratulations The GE Choice Alert Wireless Alarm System is one ™ of the most affordable and expandable wireless alarm systems available. You’ll discover that the system offers many features typically found in custom installed Alarm systems.
  • Page 4: Important Safeguards

    Important safeguards Pre Cautions 1. Do not attempt to disassemble the Water Leak Sensor, unless described in the user’s manual. There are no user serviceable parts. . Handle with Care – Avoid striking or shaking. Improper use or storage could damage the Water Leak Sensor.
  • Page 5 a signal to the Control Center. The settings on the Control Center determine if an alarm, alert or chime sounds (see Control Center Operation). The Water Leak Sensor is recommended for use on Zone 4, the alert- only Zone. If there is a leak, Zone will not sound an alarm but will sound a continuous alert until leak has stopped and water has dissipated.
  • Page 6: Installation

    Preparing the Water Leak Sensor for Installation The Water Leak Sensor is composed of two sections linked together with a cable The Sensor (transmitter) and the Probe. Before installing, remove the yellow battery isolation tape from the Sensor. This activates the Lithium battery inside.
  • Page 7: Assigning A Sensor To A Zone

    Note: If postioning the probe to a metal surface, ensure the Probe’s contacts do not touch the metal surface. Assigning the Sensor to a Zone Assigning the Sensor into a Zone is an easy four step process, however there are a few points to remember - Only one Sensor can be assigned at a time.
  • Page 8: Erasing A Sensor From A Zone

    Zone you want to assign to the Water Leak Sensor. The LED indicator for that Zone will begin to flash. Step 3 – Release the Zone button. Note: Zone 4 is for dedicated alerts only. Sensors in this Zone will not trigger an alarm or chime. Step 4 - For the Water Leak Sensor, place the contacts in a small bowl of water, or use a metal paperclip and touch both contacts.
  • Page 9: Testing A Sensor Or Your System

    Step 3 - Release all buttons. The Zone has been erased. Note: The Zone/Sensor cannot be erased if: - The Zone has been triggered for an Alert or alarm. The Sensor/Zone must be reset. - There is loss of signal from the Sensor to the Control Center (such as low battery, or Sensor is out of range).
  • Page 10: Low Battery Indicator

    reinstall batteries. This returns the Control Center to standard operation mode. Note: The Control Center will automatically return to standard operation mode after 5 hours. Low Battery Indicator The Control Center continuously monitors all the Sensors. If the Control Center does not receive a signal from any Sensor it will begin rapidly flashing the Zone LED indicator .
  • Page 11: Battery Warnings

    Model # Description 45129 Control Center 45133 Water Leak Sensor *maximum potential life based upon usage and location WARNING! Risk of personal injury - Prolonged exposure to alarm siren may cause permanent hearing loss Battery Warning! - Remove batteries before storing...
  • Page 12: F.a.q.'s 1

    Water Leak Sensor F.A.Q.’S Q. I bought a new Sensor and the Control Center will not recognize it. Why? A. First, make sure the yellow battery isolation tape has been removed and the battery is new. Second, ensure the battery is inserted into the Sensor according to polarity(+/-) markings.
  • Page 13 Q. Why does one of my Zones continually flash? A. This can be caused by 1 of 2 conditions. First condition, if it is a rapid flash it means a Sensor in the Zone has a low battery. If more than one Sensor is in a Zone, you will need to test each Sensor by putting the unit into test mode (see pg.
  • Page 14: Fcc Warning

    Any unauthorized changes or modifications to the equipment would void the user’s warranty and may conflict with both state and federal laws. The Choice Alert system complies with part 15 of the FCC rules. Operation is subject to the following conditions: 1) The Choice Alert system may not cause harmful interference.
  • Page 15 The product, if used properly, may reduce the risk of burglary, robbery, or other adverse events. However, JASCO is not an insurer, this product is neither insurance nor a guarantee that such an event will be prevented, and users should protect themselves with proper insurance.
  • Page 16 General Electric Company and is used under license to Jasco Products Company LLC, 10 E. Memorial Road, Oklahoma City, OK 73114. This Jasco product comes with a 1 year limited warranty. Visit 45133-1 www.jascoproducts.com for details. 01/09/08...
