VTech i 5867 Quick Start Manual

Installation of Battery Pack in Handset
1. Remove the battery cover by press-
ing on the indentation and sliding
downward.
2. Place the new battery cells in the
Handset with the metal contacts
i 5867 5.8GHz SYSTEM
aligned with the charge contacts in
the battery compartment.
QUICK START GUIDE
3. Replace the battery cover by sliding
it upwards.
Setup of the i 5867
1. Plug the AC power adapter into an
electrical outlet, and the DC connector
into the bottom of the Base Unit.
2. Place the Handset in the Charge
Cradle and allow it to charge for 12
Message LED
hours.
Earpiece
LCD Display
Volume
3 Mailbox Answering System
Soft/Select Key Softkey
Off/Cancel Key
On/Flash Key
BEFORE USING YOUR i 5867, CAREFULLY PEEL OFF THE PROTECTIVE
Lighted Keypad
Microphone
FILM COVERING THE DISPLAYS.
Handset Speakerphone
Sound Select
Connecting to the Telephone Line
Plug one end of the telephone line cord
into the jack on the bottom of the Base
Unit. Plug the other end of this cord into
the wall jack.
96-5652-30-00.P65 1
Checking for Dial Tone
After the battery is charged, pick up the
Handset and press ON. PHONE ON should
appear on the screen, and you should
hear a dial tone.
Setting the Time
Incoming Caller ID/Call Waiting ID will set
the clock automatically. If you wish to set
the time manually:
1. Make sure the answering system is on.
2. Press TIME/SET. The system will announce
the current clock setting, then announce
"To set date and time, press TIME/SET."
3. Press TIME/SET.
4. Press CHANGE until the system announces
the correct day, then press TIME/SET.
5. Press CHANGE until the system announces
the correct hour, then press TIME/SET.
6. Press CHANGE until the system announces
the correct minute, then press TIME/SET.
The system announces the current clock
# # #
setting.
NOTE: You can press and hold CHANGE to
advance the minutes in increments of ten.
Making Calls from the Handset
Predial - With the Handset Off, dial the
number. If you make a mistake, press
left NavKey ( ) to backspace.
Press ON or SPEAKERPHONE to call
your predialed number.
Traditional - Press ON or SPEAK-
ERPHONE. After hearing a dial tone,
dial the desired number.
1 2
Answering Calls from the Handset Clear a Wallpaper image
To clear a wallpaper image, select the icon Pictures
Press ON or any number key to an-
Select Clear Wallpaper using the NavKeys. Then press the middle NavKey
swer a call.
or left softkey to clear the wallpaper.
Press SPEAKERPHONE to answer
Picture Download
using the handsfree option.
Download Your Own Image
Hold and Mute Do you have a favorite image stored in your personal computer that you
would like to use as your i 5867 Handset wallpaper or to assign to one of
your 50 available phonebook directories? Using the provided Image Edi-
Press the HOLD soft key to tempo-
tor Software, you can view and convert your image. Once you have se-
rarily suspend the conversation.
lected your file and viewed your image in the software, use the included
Press ON to return to the call.
USB cord to send the converted image directly into the Handset. You'll
start by downloading the software into your computer.
One-Time Software Installation
Press MUTE to mute the micro-
1. Insert the enclosed Image Editor Software into your personal com
phone. You can still hear the other
puter.
caller. Press MUTE again to return to
2. You will see a pop-up window giving you three options:
the two-way conversation.
a. Install/Uninstall the Image Editor Software.
b. Browse the installation CD.
c. Visit Vtech on the web.
Pictures To install the software, click on the Install/Uninstall the Image Editor Soft
ware icon
Your i 5867 is preset with the following number of images:
3. After the installation process is complete, you will find an Image Editor
Images – 18 images
Software icon
Emotions – 9 images
Editor software.
My Pictures – 0 images
CD ROM – 25 new images
Image Download
You have the ability to assign one image as your background for the idle
Once you have installed the software, follow these steps to view and con-
screen (wallpaper) or assign a specific image to a phonebook directory in
vert your selected image.
the available 50 directories.
• Click on the OPEN
CD-ROMDisc can be found automatically. Or navigate to the direc
Set a Wallpaper image
tory where your desired image file is stored, and open the file.
• You will see your image displayed in the middle of the screen and
To set a wallpaper image, select the icon Pictures in the main menu.
inside the telephone display on the right. You can select the following
Then choose an image in one of the three (My Pictures, Images or
options to edit your image:
Emotions) menu options. Once you have selected the image, press the
softkey to set the image as your wallpaper. You will receive a
message on the screen confirming Wallpaper Set! and an audio
confirmation.
3
04/04/23, 16:43
in the main menu.
and follow the download instructions.
on your PC desktop. Click on this icon to run the Image
icon. Then the pictures in the accompanied
- Zoom In and Zoom Out
4
96-5652-30-00
ISSUE 0
