- Page 1 Analog Resistive Touch Screen Controller TSC-54/RU-F User’s Guide Arrow.com. Downloaded from...
-
Page 2: Table Of Contents
7-2. Warranty Target ..........................10 7-3. Warranty Exceptions ........................10 8. Precautions for Use ......................11 8-1. General Handling ..........................11 8-2. Others .............................. 11 Dimensional Drawing Document No. DER-S0137A Rev 1.1 ©2016 DMC Co., Ltd. Arrow.com. Arrow.com. Downloaded from Downloaded from... -
Page 3: Product Overview
This specification is applicable to TSC-54/RU-F. 1-2. Overview TSC-54/RU-F is a touch screen controller board that performs an A/D conversion of an analog signal of a 4-wire resistive touch screen, and transmits the coordinate data to the host in a 10-bit resolution serial correspondence at 9600bps and USB. -
Page 4: Peripheral Composition Overview
X-coordinates electric circuits and the other as a Y-coordinates circuits. To measure the X-coordinates TSC-54/RU-F supplies voltage, Vcc to the one of X-coordinates electrodes with GND to the other. When the touch screen is pressed under this environment the voltage of the X-coordinates resistance is detected by the Y-coordinates electrode (A_in) at the input point (x1), where the X-Y coordinate resistance layers make contact. -
Page 5: Specifications
Coordinate Resolution 10bit (1024 x 1024) area of the touch screen 3 LSB Linearity Error Input Response Time 10ms (TYP) Document No. DER-S0137A Rev 1.1 ©2016 DMC Co., Ltd. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from... -
Page 6: Connector
RS-232C Data Output RS-232C Data Input RS-232C GND Power Input *1: When you use it at 3.3V of the serial mode, please do not connect TSC-54/RU-F to Vbus of CN4. 3-2. The mounted connector Manufacturer 04FMS-1.0SP-GB-TF (LF)(SN) J.S.T. Mfg Co., Ltd S5B-PH-K-S J.S.T. -
Page 7: Interface Type
TSC-54/RU-F User’s Guide 4. Interface type TSC-54/RU-F has serial and USB interface type. You choose either type. You cannot use both these at the same time. (Notice) In the state that connected a serial and a USB cable to a computer, please do not start power on of TSC-54/RU-F and computer. -
Page 8: Packing Specification
TSC-54/RU-F User’s Guide 5. Packing Specification 5-1. Outline TSC-54/RU-F is wrapped up in the air packing of the prevention of static protection type and puts it in a packing box. 5-2. Packing material Outer case: 75 x 55 x 15 mm, clay coated newsback board... -
Page 9: Product Name Label
May : E Nov : K Jun : F Dec : L 09: Date manufactured ② S01: Control number for DMC use ③ 00001: Serial number (5 digits) Rev: Revision information (PbFree): lead free QR code: lot number [3I09S0100001] can be read with a barcode reader. -
Page 10: Changes & Improvements
5-4. Product Name Label: Label contents changes (applied from mass production) 5-3. Outer case and lot label: The example of lot number changes to be same as 5-4. Document No. DER-S0137A Rev 1.1 ©2016 DMC Co., Ltd. Arrow.com. Arrow.com. Arrow.com. -
Page 11: Warranty
§ If the product is glued onto the equipment and uninstalled. § Any malfunctions and damages caused by an improper usage and handling against the specifications and notes. Document No. DER-S0137A Rev 1.1 ©2016 DMC Co., Ltd. Arrow.com. Arrow.com. Arrow.com. -
Page 12: Precautions For Use
This document can be freely distributed, but any alternation to this document is prohibited. DMC Co., Ltd. http://www.dmccoltd.com/english/ 11F Takanawa Sengakuji Ekimae Bldg., 2-18-10 Takanawa, Minato-ku, Tokyo 108-0074, Japan Phone: +81-3-6721-6731 (Japanese), 6736 (English) Fax: +81-3-6721-6732 Document No. DER-S0137A Rev 1.1 ©2016 DMC Co., Ltd. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. - Page 13 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
